Product Details
Condition: | New | Product Type: | Other, A4 paper making machine | Processing Type: | Other, A4 paper making machine |
Place of Origin: | Henan, China | Brand Name: | Shunfu | Model Number: | 3200 type |
Voltage: | 380v | Power(W): | 100-150kw | Dimension(L*W*H): | Depends on model and configuration |
Weight: | 30-40tons | Certification: | Other, ISO9001 | Warranty: | one year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Copy paper/A4 paper/writing paper/printing paper making machine
Technical data
Output paper:writing paper, printing paper, newspaper, copy paper.
Width of jumbo roll:3200mm
Rail gauge:4300mm
Dynamic balancing speed:500m/min
Capacity:20-30T/D
Drives:AC frequency conversion speed regulator .
Processing transmission
Main frame of the equipment
Head-box section:Especially chose open type headbox, which comprises step diffuser,
perforaled roll, and so on.
Fourdrinier section:The length of fourdrinier table is 1800mm,and the stand is welded
with section steel, except the draw-out position with aluminum alloy.
Press part :Use suction feed paper leader, a series of vacuum press and three series
of straight-through press.
Drives andcontrol:AC frequency conversion speed regulator, processing transmission, digital
sealed ring control system.
All the accessory equipment
Number | Item | QTY |
1.
| 3200mm fourdrinier and multi-cylinder cultural paper making machine | 1 set |
2. | 3200mm winding machine | 1 set |
3. | 3200mm rewinding machine | 1 set |
4. | 3200mm calender | 1 set |
5. | 35m3 potcher | 6 sets |
6. | Pulp pump(6″) | 14 sets |
7. | Pulp pump(4″) | 12 sets |
8. | Vertical pressure screen | 4 sets |
9. | 450 Double disks refiner | 4 sets |
10. | Decker thickener | 4 sets |
11. | Kamyr pressure filter | 4 sets |
12. | Sand separator pump | 2 sets |
13. | Sand cleaner | 4 sets |
14. | 8m3 high consistency hydraulic pulper | 3 sets |
15. | Resin tank | 6 sets |
16. | Chemical mixing tank | 4 sets |
17. | The whole set of work bench | 1 suite |
18. | Φ1000Thruster | 12 sets |
What we can provide:
1.787,1092,1575,1760,1880,2400,2640,2800,3200mm paper machine
2.paper egg tray machine
3.pulp making equipments
4.paper making equipments
5.paper processing equipments
6.all kinds of spare parts
Best Service:
1.We will provide you all technical consultation and make the drawing and proposal for you.
2.We will send technicians to install and test the machine for you.
3.We will train skilled workers for you.
4.We will supply best pre-sale, after-sales for you.
Henan Province Qinyang Shunfu Paper Making Machinery Co; Ltd. was founded in 1988.
We are specialized in the production paper making machinery, pulping equipment, paper egg
tray making machine and paper processing equipment. Our products had been certificated by
ISO9001 and exported to many countries, such as Uzbekistan, Russia, Kyrgyzstan, Nigeria,
Ukraine, Botswana, Libya, Algeria, El Salvador, Lebanon, Moldova, Bolivia.
More detail information and scheme,please feel free to contact with me!
