PRODUCT FEATHERS
1.Top cable manufacturer with 14 branch companies.
2.Export goods to 50 countries.
3.Guarantee 30 years service life.
4. Best quality with a fair price.
QUICK INFORMATION
1.Solid or stranded,tinned or Pure copper conductor;
2.Non-sheathed single core cable ;
3.Passed the UL VW-1 & CSA FT1 vertical flame test;
4.Max.temperature of conductor :70°C.
5.Resistant to scids,oils,alkalies,moisture and fungus;
6.Rated voltage:450/750V;
7.Standards Implemented: ISO9001,ISO14004,OHSASI8000,UKAS,KEMA,TUV,CE,CESI,IEC AND SO ON.
| Conductor | solid or stranded copper |
| Insulation | PVC |
| Sheath | no outer sheath |
| core number | single core |
| Rated voltage | under or up to 450/750V |
| sectional area(mm2) | 1.5~400mm2 |
| Color | red,yellow,blue,black or customized |
| Package | plastic bag or wooden case |
450/750V Single-core rigid conductor non-sheathed copper conductor cable (BV)
|
Nominal sectional Area of conductor, mm2 |
Conductor structure, Nr./mm |
Stipulated insulation thickness, mm |
Max. average outer diameter, mm |
20 , DC, resistance ℃ ≤Ω/km |
|
1.5 1.5 2.5 2.5 4 4 6 6 10 16 25 35 50 70 95 120 150 185 240 300 400 |
1/1.38 7/0.52 1/1.78 7/0.68 1/2.25 7/0.85 1/2.76 7/1.04 7/1.35 7/1.70 7/2.20 7/2.60 19/1.87 19/2.25 19/2.60 37/2.09 37/2.32 37/2.60 37/2.95 61/2.56 61/2.95 |
0.7 0.7 0.8 0.8 0.8 0.8 0.8 0.8 1.0 1.0 1.2 1.2 1.4 1.4 1.6 1.6 1.8 2.0 2.2 2.4 2.6 |
3.3 3.4 3.9 4.2 4.4 4.8 4.9 5.4 6.4 8.0 9.8 11.0 13.0 15.0 17.0 19.0 21.0 23.5 26.5 29.5 33.5 |
12.1 12.1 7.41 7.41 4.61 4.61 3.08 3.08 1.83 1.15 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 |
