Low Pollution Marble Vibrator Feeder

Specifications

Marble Vibrator Feeder
1. Adjustable vibration force
2. Using eccentric block
3. High adjusting capability
4.High stability

Marble Vibrator Feeder



Type : Necessary Equipment



Input Size: 0-1000mm



Processed Materials: River Gravel, Marble, Granite, Basalt, Quartz, Iron ore, Diabase, Limestone, Coal Gangueetc.



Applications: Aggregate Field, Concrete Mixing Plant, Dry Motar Plant Desulfurization, Quartz Sand etc



• We manufacture professional quality Marble Vibrator Feeder used in industrial, mining, construction material, silicate and chemical plants. Our feeders are manufactured out of the most optimum quality raw materials.

• Marble Vibrator Feeder can be developed in accordance with the specific need of clients. Due to performance, quality and competitive market prices our feeders for Crusher are in great demand.

• Marble Vibrator Feeder is designed and fine tuned to assure the uniform and regular flow of materials over the crusher, screening system and to the conveyors. The settings of feeder equipments can be adjusted according to the requirement.





Features of Marble Vibrator Feeder

• It vibrates calmly, works reliably with a long life-span; its stimulating vibrancy power can be adjusted, while the flux can be changed and controlled, it is convenient and stable to adjust;
• Vibrating feeder's vibrating electrical engine is stimulating vibrancy fountain, with low noise, low cost of electricity, and good adjusting capability, without rushing phenomenon.
• Its structure is simple and works stably, and easy to adjust and install, and it is convenient to maintain and take care for its light weight and small size, and it can avoid powder and dust pollution when using the closed structural body.
• Characters: Smooth vibration, reliable operation, long service life, low noise, low power consumption, easy to adjust, simple structure, easy to install, light weight, small volume, simple maintenance.



Technical Parameters of Marble Vibrator Feeder

Model	Feed chute size (mm)	Max. feeding size (mm)	Handling capacity (t/h)	Power (kW)	Overall Dimension (mm)	Weight (including motor) (kgs)
GZD-960×3800	960×3800	500	90-160	11	3880×2240×1880	3980
GZD-1100×4200	1100×4200	600	120-240	15	4300×2450×2010	4170
GZD-1300×4900	1300×4900	600	150-400	18.5	4980×2705×2050	5200
GZD-1500×6000	1500×6000	800	460-575	30	6160×2920×2295	9000



























Working Site
