Specifications
Sand Washing Machine :1.Reasonable structure,
2. Large capacity,
3. Low consumption,
4. Low failure rate.
Sand Washing Machine
Specication Of Sand Washing Machine
Type: Necessary Equipment
Input Size: <10mm
Processed Materials: River Gravel, Granite, Basalt, Quartz, Iron Ore, Diabase, Limestone, Coal Gangueetc.
Applications: Aggregate Field, Concrete Mixing Plant, Dry Mortar Plant Desulfurization, Quartz Sand etc.
Overview Of Sand Washer Machine
XSD series sand washing machine is a kind of wheeled washing equipment, and can clean and separate the dust and powder from the sand. Its new seal-structure and reliable driving device can make sure the cleaning effect and a kind of high efficiency sand washing equipment matched with the sand making machine.
Sand washer Machine are mainly used in building site, gravel plant, concrete dam building site of hydropower station, etc., and with features of high degree cleaning-up, reasonable structure, large capacity, low power consumption, small loss of the sands during the washing process, especially for that the drive parts of the sand washing machine are separated from water and sands. So that it has lower failure rate than the usual sand washing machine.
Working Principle Of Sand Washer Machine
The electric motor runs slowly with the impellor after decelerated by the belt, decelerator and gears wheel. The sand and stone flow into washing launder from feeding launder, rolls with the impellor, and grinds each other. The impurity covering the sand is washing away. At the same time, add more water, the strong water flow will take away waste and some low-weight wastes from washing launder. Through the above process, the washing function is finished. The clean sand and stone is lift up by vane. When it goes up slowly, the water begins to drop through the mesh and fall back in the washing launder. On one hand, water is removed from the sand and stone; on the other hand, the water can be fully used. Finally, the sand and stone goes to the out launder from the rotary impellor to finish the washing task.
Technical parameters
Model |
Wheel Size (mm) |
Max feed size (mm) |
Power (kW) |
Weight (t) |
Capacity (t/h) |
Overall dimension (mm) |
XSD2610 |
Φ2600×1000 |
10 |
5.5 |
2.7 |
20-50 |
3255×1982×2690 |
XSD2816 |
Φ2800×1600 |
10 |
11 |
5.5 |
30-60 |
3540×3000×2880 |
XSD3016 |
Φ3000×1600 |
10 |
15 |
5.8 |
50-100 |
3845×3000×3080 |
Henan Teng Fei Machine Manufacturing Co., Ltd. is a professional machine mining manufacturer with decades of years' experience. Our main product are grinding mills, Crushers,Dryer,Ball Mill, Sand making&washing machines, vibrating screens, etc. They are all design ed, produced, manufactured and tested in accordance with the standard of ISO9001 quality system standard. Our products are recognized as quality products by technical supervision departments .
We manufacture TengFei brand mining machinery which are 100% of our own design, production detection and marketing.
|
Packaging Details: |
Standard export packing, seaworthy packing or as required. 1.One standard container is needed for large goods. 2.Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or IronBox. 3.Other Equipment will be packed by Color-Stripes Plastic Cloth. |
Delivery Detail: |
7-15 days after the down payment |
