High-speed coating line with powder removing section and water-based coating machine-LSGZ-C-UI1040C-A
- 50 Unit / Units per Month
- Shanghai
- 2016 Style Qingdao A4 Paper Cross Cutting Machine with low price
- Leizhan Disc sludge thickener for paper pulp making production line
- Automatic die cutting machine kiss cut cutting machine
- Efficient Operation Paperboard Wax Coating Machine with Customized Wax Content
- Corrugated Paper Box Carton Folding Gluing Machine Automatic Printing slotting
- Corrugated Paper Box Carton Folding Gluing Machine Automatic Printing slotting
Product Details
Type: | Other, Coating machine | Place of Origin: | Shanghai, China | Brand Name: | TOWIN |
Model Number: | LSGZ-C-UI1040C-A |
Product Description
Specifications
Coating machine1. High efficiency and stability
2. High precise
3. Perfect result
4. With powder removing section
LSGZ-C-UI-C-A HIGH-SPEED COATING LINE WITH POWDER REMOVING SECTION AND WATER-BASED COATING
Application:
This machine is used for coating on the surface of paper, which raises its brightness and plays a role of damp-proof and abrasion-resistance so as to protect colors on the surface of paper. It is suitable for small sized priting product.
Features:
1. Automatic feeding section: High-speed stable feeder free from maintenance.
*Option: movable guide rail, manual feeding table for paper size feeder could not handle.
2. Powder removing section: Adopt flannel roller and heating roller double way to clean the powder on paper surface and increase the coating effects, convenient adjustment and operation.
3. Grounding coating/IR drying section: This section is used for water-based varnish before UV coating to fill with small holes on paper surface to save UV varnish.
4. Infrared hot air drying/cooling fan ministry: The unique design of hot-wind drying make water-based coating frying faster and more purely.
5. UV coating/UV curing section: Adopt reverse roller and speed regulating to control varnish thickness, automatic stop for paper jam to reduce sheets to be wasted.
6. UV curing: This section is composed of lamps, reflectors, air cooling and exhasuting systems. Sheets coated by UVvarnish will be dried here.
7. Automatic delivery section: Jogging times can be set according to paper weight. Pneumatic joggers can keep sheets delivered orderly. Equipped with pre-delivery table which will be automatically open when paper jam in delivery.
Technical Parameter:
Model: | LSGZ-C-UI740C-A | LSGZ-C-UI1040C-A | LSGZ-C-UI1200C-A |
Max width(mm) | 740X560 | 920X1040 | 1200X920 |
Min width(mm) | 280x400 | 307x440 | 307x440 |
Max speed(pcs/h) | 7000 | 7000 | 7000 |
UV power: | 6.5kw x 3 | 9.75kw x 3 | 9.75kw x 3 |
IR power: | 1kw x 27 | 1.5kw x 27 | 1.8kw x 27 |
Total Power(kw) | 68 | 84 | 96 |
Weight(t) | 6.2 | 6.5 | 6.6 |
Dimension(mm) | 20000X1450X1700 | 20000x1750x1700 | 20000X1800X1700 |
