Help CenterReel Fed Flat Bed Die Cutting Machine
Related Products
-
Automatic Die Cutting MachineUS$ 100,000 - 200,000MOQ: 1 Unit -
Automatic Die Cutting Machine With Stripping and BlankingUS$ 250,000 - 350,000MOQ: 1 Unit
-
Automatic Die Cutting Machine With StrippingUS$ 200,000 - 300,000MOQ: 1 Unit
-
Automatic Web-fed Rotatry Die Cutting Production LineUS$ 200,000 - 300,000MOQ: 1 Unit
-
Semi Automatic Die Cutting & Creasing MachineUS$ 70,000 - 100,000MOQ: 1 Unit
Specifications
reel fed die cutting machine1.To die cut paper cup & bowel ups
2. Reel fed die cutting
3. High production & low cost
Applications
The machine is used die cut printed paper roll after flexo or gravure machine to produce paper cup and paper bowel ups. The machine is widely used in fast food packaging industry as its high production and low cost.
Technical specifications:
Parameter |
SP-LM880 |
SP-LM1000 |
SP-LM1250 |
SP-LM1350 |
Die cutting mode |
Reel fed, flate-bed die cutting |
Reel fed, flate-bed die cutting |
Reel fed, flate-bed die cutting |
Reel fed, flate-bed die cutting |
Max.die cutting area |
880X530mm |
1000X600mm |
1250X600mm |
1350X600mm |
Machine speed |
95 strokes/min |
90 strokes/min |
90 strokes/min |
90 strokes/min |
Die cutting pressure |
120 tons |
180 tons |
180 tons |
180 tons |
Paper weight |
135-350gsm |
170-350gsm |
190-350gsm |
220-350gsm |
Paper width |
355-880mm |
400-1000mm |
400-1250mm |
400-1350mm |
Max.Reel diameter |
≤1400mm |
≤1400mm |
≤1400mm |
≤1400mm |
2000mm (in case of using shaftless unwinding stand) |
2000mm (in case of using shaftless unwinding stand) |
2000mm (in case of using shaftless unwinding stand) |
2000mm (in case of using shaftless unwinding stand) |
|
Reel core diameter |
3’’/6’’/12’’ |
3’’/6’’/12’’ |
3’’/6’’/12’’ |
3’’/6’’/12’’ |
Compressed air |
0.5MPa |
0.5MPa |
0.5MPa |
0.5MPa |
Main motor power |
11kw/380V/50Hz |
11kw/380V/50Hz |
11kw/380V/50Hz |
11kw/380V/50Hz |
Machine weight |
4500kg |
5200kg |
6500kg |
7500kg |
Machine size |
4500x2100x1700mm |
4500x2150x1700mm |
4500x2300x1700mm |
4500x2500x1700mm |
Features:
¨Up to 10% paper can be saved with our special patented ups layout on the die. It is gapless ups layout, which is designed for reel fed die cutting and creasing.
¨Energy saving ( less labor cost and producing cost)
¨Control to positioning of reel feeding, print mark tracking, accurate auto deviation rectifying
¨Different dies with different ups layout can be used to match each paper material
¨The machine is CE certified
¨Lots of patents used in the machine
¨Improved productivity for end users
¨Widely used in printing and packaging industry
