YEESO Outdoor LED Display , Advertising Trailer YES-T9N

Name: YEESO Outdoor LED Display , Advertising Trailer YES-T9N
Brand: YEESO
SKU: 115239131
Availability: InStock

US$ 50,000 - 60,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

YEESO

Model Number:

YES-T9N

Yeeso Multimedia Mobile Tech (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name YEESO

Model Number YES-T9N

Usage Outdoor

Tube Chip Color Full Color

Display Function Animation

Pixels 10mm

Screen Dimension 5900mm x 1600mm x 2200mm

Vehicle-specified LED Display

A. Made of large chip tube, high brightness, less attenuation, the luminance

keeps over 7000cd/m , after 5 years life-span of more than 100,000 hours.

B. With our patented high-refresh rate display technology, regardless of shooting with a

camera or other photographic equipment will not result in scan lines. The entire screen is

as clear as a mirror. With the unique point by point correction technology of the control

card, the LED screen can be corrected a few years later. After the correction, the LED

screen picture will be soft again. This is an effective solution to solve screen mess

phenomenon.

C. Besides the PCB adopts four layers board, which is puncture resistant and anticorrosive,

connectors are made of horn card buckle and DB9 terminals to prevent poor contacting

damage resulting from the vehicle vibration. Besides the waterproof design of each cabinet,

Trailer Chassis
Brand	YEESO		External dimension	5900mm×1600mm×2200mm
Max Speed	60km/h		Gross mass	2100KG
Lifting and Rotating System
Lift Type	Hydraulic putt system		Lifting Height	1500mm~1800mm
Rotating Type	Hydraulic rotary system		Rotation Angle	360 degree
LED Display System
Screen size	4000mm×2400mm	Module size		160mm(W) ×160mm(H)
Chip	R,G,B:EPISTAR	Pixel pitch		10 mm(outdoor)
Brightness	≥7000cd/ m²	Max power consumption		1000 W/ m²
Life span	100,000hour	Average power consumption		500W/ m²
Silent Generator
Brand	Yeeso	Power		13KW
Outer Power Supply
Input voltage	AC380V	Output Voltage		AC220V
Electrical Current	50A	Power consumption		Average:0.8wh/m²
Multi-media control System
Control System	synchronous control card	Speakers: 200W, amplifier, video processor
Outer Frame
Frame Material	Cold rolled metal plate	Surface Color		Pure white car baking varnish
