J32 advantages lathe machine
1. specification of J32 advantages lathe machine
| max. swing over bed | 190 mm |
| max. swing over cross slide | 80 mm |
| max. processing length | 200 mm |
| spindle bore | 37 mm |
| max. diameter of the bar |
32 mm |
| spindle speed | 150-3000rpm |
| X/Z fast feeding speed | 8/10 m/min |
| spindle motor | 3 kw |
| tool post |
gang type tool post |
| tailstock |
No |
| n.w. | 800 kg |
| machine dimension | 1450*1100*1600 mm |
2. usage of J32 advantages lathe machine
This CNC lathe machine is widely used in the lines of the electrical appliance,instrumentation
industry, automobile, motorcycle, fastener bearings, photographic and film machinery,
hardware tools,watches, glasses, stationery, motors, valves and gas pipe, other high
precise and complex components.
This lathe machine could process different inner bore, ex-circle, circular conical, surface and screw
thread, especially for the small and middle size shaft and plate work piece. It has the advantages
like higher automatically, simpler programming and higher stability.
3. standard accessories of J32 CNC lathe for sale in Dubai/ export to Dubai
4 piece gang type tool post
pneumatic collet
complete coolant system
complete lubrication system
advanced LED work light
tool box and lots of tools like wrenches, machine feet, screw drivers, allen wrench etc.
4. optional accessories of J32 advantages lathe machine
Tail stock
4 station electric tool carrier
5" manual chuck
hydraulic chuck, hydraulic station and hydraulic rotary cylinder
hydraulic collet
chip conveyor
5. factory and machine pictures
Before order, please kindly inform the following,
1.Work piece max. length, max. O.D., material etc
2.Work piece drawings
3. Need cutters, clamping set or not
4.Custom service
Click " send " now and learn more about our products.
Please talk with us on alibaba TM right now.
