ace cnc lathe machines
1. specification of TCK6336S ace cnc lathe machines
| ace cnc lathe machines | TCK6336S |
| Max. swing over bed |
390 mm |
| Max. swing over cross slide | 130 mm |
| Spindle speed | 3500 rpm |
| Spindle nose | A2-6 |
| Spindle bore | 56 mm |
| Max. bar diameter | 45 mm |
| work piece clamping type | 6" hydraulic collet chuck |
| Spindle motor | 5.5 kw |
| X/Z feed motor power | 1.5 kw |
| X/Z feed motor torque | 6/6 Nm |
| X/Z position accuracy |
0.016/0.016 mm |
| X/Z repeatability |
0.006/0.006 mm |
| X/Z rapid feed speed | 18/15 m/min |
| Cutting tool shape size | 20*20 mm |
| Total power capacity | 9 kva |
| Machine dimension (L*W*H) | 2500×1340×1710 |
| N.W. | 2500 kg |
block diagram lathe machine
2. Features of TCK6336S ace cnc lathe machines
45 degrees slant bed CNC lathe
Higher accuracy Taiwan linear
Chip conveying capacity is large and convenient, customer could choose
chip conveying in the front or in the back
Screw pre-stretching structure
Gang type tool post
3. Usage of TCK6336S ace cnc lathe machines
This machine is applicable to automobile, motorcycle, electronics, aerospace, military, oil and other
industry. It could turn the conical surface, circular arc surface, end face of the rotary parts, could
also turn various metric and inch threads etc, with higher efficiency and higher precision in bulk.
4. Standard accessories of TCK6336S ace cnc lathe machines
GSK980TDC or Siemens 808D NC system
servo motor 3.7 kw
4 station gang type tool post
6" domestic thru-hole type hydraulic chuck
5. Optional accessories of TCK6336S ace cnc lathe machines
NC System: KND1000Ti, Fanuc Oi Mate-T
Main Motor: Servo5.5/7.5KW
Inverter 7.5KW
Turret: 4 station electric turret , 6 station electric turret
Chuck: 6″Non-through hole hydraulic chuck
8″Non-through hole hydraulic chuck (Taiwan)
8″through hole hydraulic chuck(Taiwan)
Chip conveyor
Steady Rest
Other optional item: Driving tool turret, automatic feeding device and manipulator.
