Folding Type Thin Rice Vermicelli Noodle Making Machine/Rice Vermiceli Machine/Rice noodle making machine
The products show: folding type rice vermicelli/ rice vermicelli noodle
rice vermicelli process as following
Mixing the rice flour --flour ripening---lifting rice flour to the flour feeder ---feeding rice flour to extruder --- first extrusion --second extrusion ---rice vermicelli ---rice vermicelli first aging ---rice vermicelli steaming ---rice vermicelli second aging ---rice vermicelli washing ---folding and drying---rice vermicelli cooling ---packaging
Note: This rice vermicelli production process is based on Chinese method. But we can adjust the process as the customer's special requirement.
The Thai & Indian rice vermicelli process as following
Mixing the rice flour --steaming the rice flour ---lifting rice flour to the flour feeder ---feeding rice flour to extruder ---rice vermicelli extruding ---rice vermicelli forming ---rice vermicelli steaming --- rice vermicelli aging ---rice vermicelli washing ---folding and drying---cooling ---packaging
The Features : rice vermicelli making machine/rice vermicelli machine
|
1 Highly automatic controlled production line which realizes the continuous production of the first aging, steaming, second aging, vermicelli loosing and drying. |
|
2 In order to guarantee the high quality of the products and achieve the industrialized production, the whole production line is controlled by scored of frequency converters and PLC which could adjust technical parameters for each unit. |
|
3 The aging tunnel is adopted the multi-levels with humidy and temperature controlled system which shorten the aging time, save the energy resource and low down the cost of production. |
|
4 The automatic vermicelli loosing machine which save a great labor and improve the profit space of production. |
|
5 In order to meet the demands of drying curve and achieve the better drying effect, the drying tunnel is adopted the up and down multi-level design and strict control of humid and temperature in each section. |
Models: Folding type rice vermicelli noodle making machine/rice vermicelli machine/rice noodle making machine
|
Model |
Daily output (ton) |
Dimension (L x W x H)m |
Compressed air (m3/min) |
Steam Kg/h |
Power Kw |
Operator |
LR4 |
4 |
56.4 x 3 x 3.6 |
0.7 |
700 |
80 |
10+ |
LRV7 |
7 |
71 x 3 x 3.6 |
1.2 |
1000 |
120 |
12+ |
LRV15 |
15 |
96 x 4.7 x 3.6 |
1.6 |
1500 |
200 |
15+ |
Service System
our company supples excellent pre-sales to after-sales service
1 supply solutions according to the buyer's special demands
2 design the total installation of the manufacturing line
3 supply information of the related device
4 install the machine, provide the technicial assistance both at check-up and startup
5 train the operators
Welcome to SNT Machinery
Saint Ngong Tat Machinery Company (Tianjin) Limited (SNT for short) is the sole-venture
enterprise of Wang Wai Tat Machinery Company (Hong Kong) which specializes in the extruding
technology noodles making machine. SNT Machinery was established in Tianjin 1992. We have
developed several series of noodle machines, such as non-fried instant noodle, instant rice
noodle, rice vermicelli, stick rice vermicelli, starch vermicelli and vermicelli production line etc.
