Industrial Folding Type Rice Vermicelli Making Machine/Rice Vermicelli Machine
The whole process is high automatic except the folding process. It have continuous first aging, steaming,second aging, washing. Labor fold the shape then contious drying and cooling. Due to the extruding technology, it can process various of flours, including the rice flour, mungbean starch ,corn starch,wheat,semolina,ragi, millet et
The folding rice vermicelli
Automatic Rice Vermicelli Making Machine/Rice
Vermicelli Machine
rice vermicelli process as following based on Chinese method
Mixing the rice flour --flour ripening---lifting rice flour to the flour feeder ---feeding rice flour to extruder --- first extrusion --second extrusion ---vermicelli forming ---first aging ---steaming --- second aging ---washing ---folding ---drying ---cooling --packaging
Note: The rice vermicelli process has some changes in different areas. We can design the process accroding to the customer's special requirement.
Thai rice vermicelli process
Mixing the rice flour --steamed the mixed well rice flour ---lifting rice flour to the flour feeder ---feeding rice flour to extruder --- extruding ---vermicelli forming - ---steaming the rice vermicelli --- aging ---washing ---folding ---drying ---cooling --packaging
Models : Rice Vermicelli Machine Plant/Rice Vermicelli Making Machine
|
Model |
Daily output (ton) |
Dimension (L x W x H)m |
Compressed air (m3/min) |
Steam Kg/h |
Power Kw |
Operator |
LR4 |
4 |
56.4 x 3 x 3.6 |
0.7 |
700 |
80 |
10+ |
LRV7 |
7 |
71 x 3 x 3.6 |
1.2 |
1000 |
120 |
12+ |
LRV15 |
15 |
96 x 4.7 x 3.6 |
1.6 |
1500 |
200 |
15+ |
The Features: Industrial thin rice vermicelli making machine/rice vermicelli machine
|
1 Highly automatic controlled production line which realizes the continuous production of the first aging,steaming, second aging, vermicelli loosing and drying. |
|
2 In order to guarantee the high quality of the products and achieve the industrialized production, the whole production line is controlled by scored of frequency converters and PLC which could adjust technical parameters for each unit. |
|
3 The aging tunnel is adopted the multilevels with humid and temperature controlled system which shorten the aging time, save the energy resource and low down the cost of production. |
|
4 The automatic vermicelli loosing machine which save a great labor and improve the profit space of production. |
|
5 In order to meet the demands of drying curve and achieve the better drying effect, the drying tunnel is adopted up and down multi-level design and strict control of humid and temperature in each section. |
Service System
our company supples excellent pre-sales to after-sales service
1 supply solutions according to the buyer's special demands
2 design the total installation of the manufacturing line
3 supply information of the related device
4 install the machine, provide the technicial assistance both at check-up and startup
5 train the operators
Welcome to SNT Machinery
Saint Ngong Tat Machinery Company (Tianjin) Limited (SNT for short) is the sole-venture
enterprise of Wang Wai Tat Machinery Company (Hong Kong) which specializes in the extruding
technology noodles making machine. SNT Machinery was established in Tianjin 1992. We have
developed several series of noodle machines, such as non-fried instant noodle, instant rice
noodle, rice vermicelli, stick rice vermicelli, starch vermicelli and vermicelli production line etc.
