MDC Pulse Bag Type Dust Collector for Fabric and Saw Powder
US$ 2,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Fabric Dust Collector
Efficiency:
99.9%
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Efficient Industrial Cyclone Dust CollectorUS$ 1,500 - 3,400MOQ: 1 Set -
Obstructed GSC Series Hindered Settling MachineUS$ 1 - 30,000MOQ: 1 Set
-
Bag Dust Collector With Best PriceUS$ 2,000 - 100,000MOQ: 1 Set
-
MDC Filter Cartridge Type Industrial Dust Collector for Silica SandUS$ 2,000 - 100,000MOQ: 1 Set
-
Quartz Crushing Machine /crusherUS$ 2,000 - 20,000MOQ: 1 Set
Condition
New
Type
Fabric Dust Collector
Efficiency
99.9%
Minimum Particle Size
0.5 Micron
Place of Origin
Shandong, China
Brand Name
GUOTE
Model Number
MDC
Dimension(L*W*H)
Different model
Weight
1~84ton
Certification
ISO9001:2008
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
MDC pulse bag type dust collector
Product Description
APPLICATION
This product is widely used in cement,mineral processing,electronics, chemical industry ,food processing, metallurgy, casting, carbon materials, machinery processing, wood for building materials industry.
OPERATIONAL PRINCIPLE
Dust containing gas from the inlet into the dust collector, box, through filtration bag, the dust and gas separation, the dust is adsorbed on the surface of clean air through the filter bag.Filter bag is discharged from the air outlet,deposition in more dust and the bag surface increased with time, according to the injection procedure setting, pulse jet valve receives issued by the controller, in order to trigger the opening, gas bag of compressed air ejected from the moment each hole blowing pipe, the scripture’s jet to corresponding filter bag, filter bag dust adsorbed on the surface dust fall off, fall into the bucket, the discharged ash valve or directly into the cabin.
TECHNICAL PARAMETER
| MODEL | symbols and data | |||||||||||
| A | B | C | D | E | G | H | I | K | L | M | N | |
| MDC-24 | 1450 | 1000 | 560 | 1410 | 960 | 2306 | 2575 | 466 | 441 | 339 | 400 | 300 |
| MDC-36 | 1450 | 1400 | 755 | 1410 | 1360 | 2306 | 2575 | 466 | 441 | 339 | 400 | 300 |
| MDC-48 | 1450 | 1800 | 955 | 1410 | 1760 | 2306 | 2575 | 870 | 840 | 339 | 800 | 300 |
| MDC-60 | 1450 | 2200 | 1155 | 1410 | 2160 | 2306 | 2575 | 870 | 840 | 339 | 800 | 300 |
| MDC-72 | 1450 | 2600 | 1400 | 1410 | 2560 | 2306 | 2575 | 870 | 840 | 339 | 800 | 300 |
| MDC-84 | 1450 | 3000 | 1555 | 1410 | 2960 | 2306 | 2575 | 1270 | 1240 | 339 | 1200 | 300 |
| MDC-92 | 1450 | 3500 | 1855 | 1410 | 3450 | 2306 | 2575 | 1270 | 1240 | 339 | 1200 | 300 |
| MDC-108 | 1450 | 3900 | 2035 | 1410 | 3850 | 2306 | 2575 | 1450 | 1400 | 339 | 1360 | 300 |
| MDC-120 | 1450 | 4300 | 2235 | 1410 | 4250 | 2306 | 2575 | 1450 | 1400 | 339 | 1360 | 300 |
| MDC pulse bag type dust collector | |||||||||
| technical parameter | model and specifications | ||||||||
| MDC-24 | MDC-36 | MDC-48 | MDC-60 | MDC-72 | MDC-84 | MDC-92 | MDC-108 | MDC-120 | |
| filtration area/ m² | 18 | 27 | 36 | 45 | 54 | 63 | 72 | 81 | 90 |
| the number of the filter bags/pcs | 24 | 36 | 48 | 60 | 72 | 84 | 96 | 108 | 120 |
| bag specifications/mm | Φ127×2000 | ||||||||
| working temperature/℃ | <120 | ||||||||
| equipment resistance/Ω | 1000-1500 | ||||||||
| dedust efficiency | 99 | ||||||||
| the dust concentration at the inlet mg/m³ | <15 | ||||||||
| filtration velocity m/min | 0.5-4 | ||||||||
| airflow m³/h | 540-4300 | 810-64800 | 1080-8640 | 1350-10800 | 1620-12900 | 1890-15100 | 21600-17200 | 2430-19400 | 2700-21600 |
| blowing air pressure /pa | 0.5-0.7 | ||||||||
| pulse valve/pcs | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 |
| pulse width/s | 0.1-0.2 | ||||||||
| pulse period/s | 60-120 | ||||||||
| pulse interval/s | 1-5 | ||||||||
| dimension/mm×mm×mm | 1100*1685*2527 | 1500*1685*2527 | 1900*1685*2527 | 2300*1685*2527 | 2700*1685*2527 | 3100*1685*2527 | 3600*1685*2527 | 4000*1685*2527 | 4400*1685*2527 |
