Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > QDA Electric Submersible Pump,clean Water Pump,New Arrival

QDA Electric Submersible Pump,clean Water Pump,New Arrival

Name: QDA Electric Submersible Pump,clean Water Pump,New Arrival
Brand: BALLENA,UNIPOMPE
SKU: 113797827

QDA Electric Submersible Pump,clean Water Pump,New Arrival thumbnail-1

QDA Electric Submersible Pump,clean Water Pump,New Arrival photo-1

US$ 15 - 60 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

BALLENA,UNIPOMPE

Model Number:

QDA

Contact Supplier Request Quote Chat Now

Umex (Ningbo) Imp. & Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name BALLENA,UNIPOMPE

Model Number QDA

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Water

Power Electric

Standard or Nonstandard Standard

Pressure High Pressure

Application Submersible

Specifications

electric submersible pump,clean water pump
compact and light
aluminum pump casing & impeller
water depth max. 5m

QDA SERIES ELECTRIC SUBMERSIBLE PUMP,CLEAN WATER PUMP

RANGE OF PERFORMANCE
8Flow rate up to 668 l/min (40 m³/h)
8Head up to 32 m

LIMITS OF USE
8Maximum operating depth 5m below waterlevel.
8Environment temperature up to +40°C
8PH value in water :4-10
8Maximum passage for suspended solids 2mm

WORKING PRINCIPLE
8The pumps are fitted with an open or closed impeller ,which is mounted on the end of the drive shaft and enclosed by a large circular chamber and a baseplate is directly in contact with the fluid to be pumped.
8The rotation impeller transmits kinetic energy to the fluid which is centrifuged in the ring chamber ,where part of the kinetic energy id tranformed into pressure energy, the particular design of the impeller optimizes hydraulic efficiency ,while allowing the pump to the handle muddy fluids containing solids in suspension and short fibres without danger of clogging.

STRUCTURAL CHARACTERISTIC
8Pump body : Aluminium
8Impeller : Cast iron/Aluminium
8Motor body : Aluminium
8Mechanical seal : Stainless steel/Carbon-Ceramic
8Shaft : 45# steel or SS420
8Bearing : SKF, C&U or local China
8Insulation class : B
8Protection class : IP 68
8With float switch (or without).
8With thermal overload protector in single phase motor.

WARRANTY: 1 YEAR (according to our general sales conditions)

Model	Rated power		Rated-flow	Rated-head	Voltage	Speed	Outlet	Dimension
Model	[Kw] [HP]		[m3/h]	[m]	v	rpm	[mm]	mm
QDA1.5-12-0.25(F)	0.25	0.3	1.5	12	220/380	2860	25	350160130
QDA1.5-15-0.37(F)	0.37	0.5	1.5	15	220/380	2860	25	390195165
QDA1.5-20-0.55(F)	0.55	0.7	1.5	20	220/380	2860	25	395270240
QDA3-18-0.55(F)	0.55	0.7	3	18	220/380	2860	32	395270240
QDA6-14-0.55(F)	0.55	0.7	6	14	220/380	2860	40	395270240
QDA10-10-0.55(F)	0.55	0.7	10	10	220/380	2860	50	395270240
QDA1.5-32-0.75(F)	0.75	1	1.5	32	220/380	2860	25	420240220
QDA3-24-0.75(F)	0.75	1	3	24	220/380	2860	32	420240220
QDA6-18-0.75(F)	0.75	1	6	18	220/380	2860	40	420240220
QDA10-14-0.75(F)	0.75	1	10	14	220/380	2860	50	420240220
QDA15-10-0.75(F)	0.75	1	15	10	220/380	2860	64	420240220
QDA25-7-0.75(F)	0.75	1	25	7	220/380	2860	75	420240220
QDA3-30-1.1(F)	1.1	1.5	3	30	220/380	2860	25	530260270
QDA10-20-1.1(F)	1.1	1.5	10	20	220/380	2860	50	530260270
QDA25-9-1.1(F)	1.1	1.5	25	9	220/380	2860	64	530260270
QDA40-8-1.1(F)	1.1	1.5	40	8	220/380	2860	75	530260270
