Horizontal Boring Machine

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

CNC or Not:

Normal

Place of Origin:

China

Shanghai THL Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Place of Origin China

Brand Name THL

Model Number TX611

Specifications

1.Equipped with rectangular guideways, our horizontal boring machine is featured for its high rigidity spindle system.

Model		Units	TX611B	TX611C	TX611C/4
Table size		mm	1010×1320
Loading of table		Kg	5000
Size of T-slot		T- mm	7-22-125
Travel	X	mm	850	1200	1800
	Y	mm	900	900	1200
	Z	mm	1100	1100	1100
	W	mm	550	550	550
Distance from spindle center to worktable		mm	5-905	5-905	5-1205
Max. boring diameter		mm	240
Max. machining diameter of facing plate		mm	360
Max. drilling diameter		mm	50
Spindle diameter		mm	110 or 130
Speed range		rpm	12-950
Spindle speed step		mm	18steps
Spindle inner taper		mm	morse No.6
Diameter of facing plate		mm	550
Travel of facing plate		mm	160
Speed range of facing plate		rpm	4-160
Facing plate speed step		mm	16steps
Rapid speed	X/Y/Z	mm/min	1800
	W	mm/min	3600
	Facing plate’ rack	mm/min	1120
Feeding range on head stock and worktable while spindle rotates one circle		mm	0.025-8
Feeding range on head stock and worktable while facing plate rotates one circle		mm	0.075-24
Feeding range on rack while facing plate rotates one circle		mm	0.05-16
Weight of machine		Kg	12000	13500	16000
Total electric capacity		KVA	35	35	35
Size of machine		mm	5016×2628×2788	5016×3149×2788	5016×3789×3148
