Best Selling PVC Insulated 4 core 1.5mm2 Copper Control Cable
Application: CU/PVC/PVC Control Cables are used in interconnection of process control, communication & panel control systems like industry plant, Power plants, Natural gas and petroleum plants,etc
Specifications:
Conductors: plain copper wire , stranded
Insulation: PVC compound , 70°C grade
Separator: Polyester tape
Individual shield: Aluminum foil-polyester tape with solid / Solid tinned copper drain wire for each pair.
Overall shield: Aluminum foil-polyester tape with solid / Solid tinned copper drain wire
Inner Sheath: PVC Compound , 70°C grade
Armour: Galvenized round steel wire
Out Sheath: PVC Compound , 70°C grade
Sheath Colour: Black or according to customers request
Voltage: 300/500V , 450/750V , 600/1000V
Operating temperature with PVC insulation: Maximum 70°C
a. for non-armoured cable and flexible shielded cable, the bending radius should not be less than 6 times the outer diameter;
b. for armoured or copper-tape shielded cable, the bending radius should not be less than 12 times the outer diameter;
Model |
Description |
Application |
KVV |
copper conductor, PVC insulated, PVC sheathed, control cable |
Suitable for being laid indoors, in cable trench, pipelines or other specific occasions. |
KVVP |
copper conductor, PVC insulated, PVC sheathed, braided, shielded, control cable |
Suitable for being laid indoors, in cable trench, pipelines or other specific occasions that demands shielding. |
KVVP2 |
copper conductor, PVC insulated, PVC sheathed, copper-tape shielded, control cable |
|
KVV22 |
copper conductor, PVC insulated, PVC sheathed, steel-tape armored, control cable |
Suitable for being laid indoors, in cable trench and pipelines, directly burial or other specific occasions with a relatively large capacity for mechanical stretching force. |
KVV32 |
copper conductor, PVC insulated, PVC sheathed, thin steel wire-armored, control cable |
Suitable for being laid indoors, in cable trench, pipelines, silo or other specific occasions that demands shielding. |
KVVR |
copper conductor, PVC insulated, PVC sheathed, flexible, control cable |
Suitable for being laid indoors and places that demands moving cables with flexibility. |
KVVRP |
copper conductor, PVC insulated, PVC sheathed, braided shielded, flexible, control cable |
Suitable for b |
