British Standard Extra flexible Copper Conductor Thermoplastic PVC Insulation H03VVF / H05VVF / 6181B / 6181XY Control Cable
H03VV-F
300 V Extra-.flexible Copper Conductor, Thermoplastic PVC Insulation and Jacket
Application: H03VVF is cord for use in machine tools and electrical appliances. Excellent .
flexibility in cold temperatures and can be used indoors and outdoors ambient for portable equipment. Conductor
Extra flexible copper conductor
Insulation: Flexible thermoplastic PVC 70°C for normal operation
Core: 2, 3 or 4 conductors cabled together
Jacket: Integral flexible thermoplastic PVC
Product Code : H03VV-F | ||
Number of Cores |
2 |
3 |
Conductor Material |
Copper |
Copper |
Core Size(mm2) |
0.50/0.75 |
0.5/0.75 |
Number of Strands |
16/24 |
16/24 |
Strand Size |
0.20 |
0.2 |
Insulation Material |
PVC |
PVC |
Max Voltage |
500 |
500 |
Pallet Quantity |
15000 |
12500 |
Outer Sheath |
PVC |
PVC |
Sheath Colour |
Black or White |
Black or White |
Weight (kg/km) |
44/53 |
49/59 |
50MT Drum |
Yes |
Yes |
100MT Drum |
Yes |
Yes |
H05VVF
300/500V Extra-flexible Copper Conductor, Thermoplastic PVC Insulation and Jacket Control Cable Application
Application: H05VVF is cord for use in machine tools and electrical appliances.
Excellent flexibility in cold temperatures and can be used indoors and outdoors ambient for portable equipment.
Conductor: Extra flexible copper conductor
Insulation: Flexible thermoplastic PVC 70°C for normal operation
Core: 2, 3 or 4 conductors cabled together
Jacket: Integral flexible thermoplastic PVC
Product Code : H05VVF | ||||
Number of Cores |
2 |
3 |
4 | 5 |
Conductor Material |
Copper |
Copper |
Copper | Copper |
Core Size(mm2) |
0.75/1.00/1.50/2.50 |
0.75/1.00/1.50/2.50 |
0.75/1.00/1.50/2.50 | 0.75/1.00/1.50/2.50 |
Number of Strands |
24/32/30/50 |
24/32/30/50 |
24/32/30/50 | 24/32/30/50 |
Strand Size |
0.20/0.20/0.25/0.25 |
0.20/0.20/0.25/0.25 |
0.20/0.20/0.25/0.25 | 0.20/0.20/0.25/0.25 |
Insulation Material |
PVC |
PVC |
PVC | PVC |
Max Voltage |
500 |
500 |
500 | 500 |
Pallet Quantity |
12500/10000/8000/7500 |
10000/8000/7500/6000 |
7500/7500/5000/5000 | 7500/6000/5000/4000 |
Outer Sheath |
PVC |
PVC |
PVC | PVC |
Sheath Colour |
Black or White |
Black or White |
Black or White | Black or White |
Weight (kg/km) |
63/73/98/150 |
74/86/116/176 |
89/110/155/219 | 110/130/195/290 |
50MT Drum |
Yes |
Yes |
Yes | Yes |
100MT Drum |
Yes |
Yes |
Yes | Yes |
6181B Control Cable
Extra-flexible Copper Conductor XLPE Insulation and LSF Jacket Control Cable
Application: 6181B is cord for use in machine tools and electrical appliances.
Conductor: Extra flexible copper conductor
Insulation: XLPE insulation
Core: Single core conductor
Jacket: Low smoke Halogen Free jacket
Number of Cores |
1 |
Conductor Material |
Copper |
Core Size (mm2) |
50/70/95/120/150/185/240/300/400/500/630 |
Number of Strands |
19/19/19/37/37/37/61/61/61/61/127 |
Strand Size |
1.78/2.14/2.52/2.03/2.25/2.32/2.25/2.25/2.85/3.2/2.52 |
Insulation Material |
XLPE |
Max Voltage |
1000 |
Outer Sheath |
LSF |
Sheath Colour |
Black |
Nom OD MM |
14.7/16.5/19/20.6/22.7/25.2/28.2/31.4/35/38.8/42.9 |
Weight (kg/km) |
-/787/1052/1447/1649/2026/2659/3253/4115/5116/6340 |
6181XY Control Cable
Extra-flexible Copper Conductor XLPE Insulation and PVC Jacket Control Cable
Application: 6181XY is cord for use in machine tools and electrical appliances.
Conductor: Extra flexible copper conductor
Insulation: XLPE insulation
Core: Single core conductor
Jacket: PVC Black jacket
Number of Cores |
1 |
Conductor Material |
Copper |
Core Size (mm2) |
50/70/95/120/150/185/240/300/400/500/630 |
Number of Strands |
19/19/19/37/37/37/61/61/61/61/127 |
Strand Size |
1.78/2.14/2.52/2.03/2.25/2.32/2.25/2.25/2.85/3.2/2.52 |
Insulation Material |
XLPE |
Max Voltage |
1000 |
Outer Sheath |
PVC |
Sheath Colour |
Black |
Nom OD MM |
14.7/16.5/19/20.6/22.7/25.2/28.2/31.4/35/38.8/42.9 |
Weight (kg/km) |
-/787/1052/1447/1649/2026/2659/3253/4115/5116/6340 |
Packaging & shipping
Packaging Detail: export wooden drum ,wooden iron drum and other export standard package
Delivery Detail: 10 days and also depend on the quantity
Our service
we are one of the biggest manufacture in china mainland. We will give you a perfect shopping experience . If you need visit our factory , we will meet you at the airport or train station.
Also we can offer other service
Custom Merchandise:we can make cable as your need include the color ,size and so on.we also offer OEM .
Complete Course Tracking:we can offer you the service from the business begin to you get the cable and use it .
Company information
Cable sample: we can offer the sample free .
Zhengzhou hongda cable Co., Ltd.
Established Year:1999
Registered capital of RMB:5,000,000
Factory Area:300,000m2
Main products:
Areial bundle cable ,XLPE insulated power cable ,PVC insulated power cable ,electrical wire ,bare aluminum conductor(AAC AAAC ACSR )and so on
Main export county:
USA Philippines Malaysia Indonesia Venezuela, Colombia Mexico
Dominica India South Africa Zambia Kenya and so on .
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Attractive design and various styles
5. Free issue:packaging list,invoice,CD installation
6. Powerful technology R&D team
7. Strict quality assurance system and perfect testing means
8. Advanced process equipment
9. Painted with powerful antiseptic Anticorrosion material paints
10. Delivery on time
11. Our roller coaster sales to Middle East,Africa,Russia,Southeast Asia, etc.
12.We have a good reputation in the overseas
Contact information
Any needs or question ,please contact us ,we will be more pleasure to service you.
We are looking forward to your inquiry and nice cooperaton.
