Computer cable supplier , computer cable manufacturer
ISO9001
Factory
OEM
SGS
CCC certification
1.Material: Coper
2.Rated voltage: 300/500V, 450/750V, 0.6/1 kV or as your need
3.No. Of cores : 2, 3, 4, 5, 6, 7, 8, 10, 12, 14, 16, 19, 24, 27, 30, 37, 44, 48, 52, 61
4.Standard: GB/T9330, IEC or customers' requirement.
5.Insulation: PVC, XLPE, PE
6.Sheath:PVC, PE, XLPE
7.Armor: Steel wire, Steel tape
8.Application: Suitable for chambers, tunnels and ducts, light-current control system and heavy-current magnetic interference region etc.
9.Nominal cross section area: 0.5~10mm² or other
Application:
Type |
Name |
Application Site |
KVV |
Copper conductor PVC insulated & sheathed control cable |
Permanent installation indoors,in cable ditches or pipes |
KVVP |
Copper conductor PVC insulated & sheathed copper wire braiding screened control cable |
Permanent installation indoors,in cable ditches or pipes where shielding is required |
KVVP2 |
Copper conductor PVC insulated & sheathed,control cable with copperl tape shield |
Permanent installation indoors,in cable ditches or pipes where shielding is required |
KVV22 |
Copper conductor, PVC insulated & sheathed,control cable with steel tape armmoured |
Permanent installation indoors,in cable ditches ,pipes or underground be able to bear stronger outer mechanical force |
KVVR |
Copper conductor, PVC insulated and sheathed flexible control cable |
Iinstallation indoors where flexibility and movability are required |
KVVRP |
Copper conductor, PVC insulated & sheathed, braiding screened flexible control cable |
Iinstallation indoors where flexibility shielding and movability are required |
ZR-KVV |
Copper conductor PVC insulated & sheathed,flame retardant control cable |
For laying indoors, in trenched, in ducts and for fixed installation, the cable should be flame retardant |
ZR-KVVP2 |
Copper conductor PVC insulated & sheathed flame retardant control cable with steel tape shield |
For laying indoors, in trenched, in ducts and for fixed installation, the cable should be flameretardant |
ZR-KVV2 |
Copper conductor PVC insulated & sheathed flame retardant control cable with steel tape armour |
For laying indoors, in trenched, in ducts and underground, the cable should be flame retardant and able to bear beavier external mechanical force, and for fixed installation |
ZR-KVVR |
Copper conductor PVC insulated & sheathed flame retardant flexible control cable |
For laying indoors, and the cable should be flame retardant flexible and movable |
The control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.
We can product other product and accept OEM .If you have any question or requirement ,pls contact me .
Other product:
Power cable
Rubber cable
Control cable
Shided cable
Mining cable
Special cable
1. Your inquiry related to our products or prices will be replied in 24 hours.
2. Well-trained and experienced staffs to answer all your inquires in fluent English.
3. Distributorship are offered for your unique design and some our current models.
4. OEM/ODM any your customized points, we can help you to design and put into product.
5. Protection of your sales area, ideas of design and all your private information.
Yiteng Cable Technology Hebei Co., Ltd. is a specialized wire and cable manufacturer and exporter in China. We have also got the certificates of ISO9001:2008, ISO14001:2004 and our products have been approved by UL, CSA and CCC. We can manufacture the cables, wires and conductors based on different standards, like Chinese National Standard(GB), IEC, ASTM, BS, NF C, DIN, VDE, EN, AS/NZS, IS, JIS, etc.
