PVC Insulated Control Cables
Standards:
GB9330-88; IEC60227(60502, 60332); SABS.
Application:
The control cables are suitable for the wiring of electrical controlling equipments and instrument, monitoring and controlling return circuit, electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.
Service Conditions
1. The long-time working temperature of PVC insulated cable is 70° C
The long-time working temperature of XLPE insulated cable is 90° C
2. The temperature for laying the cables can not be lower than 0° C
Permissible bending radius(r): Unarmoured cable: R ≥ 6D; (D: Outer diameter of the cable); Armoured or copper-tape screened cable: R ≥ 12D; Shielded flexible cable: R ≥ 6D
Model and Data
Type |
Specification |
Nominal Cross-sectional Area (mm ² ) |
Core Quantity |
Application |
KVV |
Copper Conductor, PVC Insulated and Sheathed Control Cable |
1.0, 1.5, 2.5 |
2-61 |
Installed indoors, in cable ditches or pipes |
4, 6 |
2-14 |
|||
10 |
2-10 |
|||
KVVP |
Copper Conductor, PVC Insulated & Sheathed, Braiding Shielded Control Cable |
1.0, 1.5, 2.5 |
2-37 |
Installed indoors, in cable ditches or pipes where shielding is required |
4, 6 |
2-14 |
|||
10 |
2-10 |
|||
KVVP2 |
Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Control Cable |
0.75, 1.0, 1.5, 2.5 |
4-61 |
Installed indoors, in cable ditches or pipes where shielding is required |
4, 6 |
2-14 |
|||
10 |
4-10 |
|||
KVV22 |
Copper Conductor, PVC Insulated and Sheathed, Steel tape Armored Control Cable |
1.0, 1.5, 2.5 |
4-61 |
Installed indoors, in cable ditches. Be able to withstand strong external mechanical force |
4, 6 |
2-14 |
|||
10 |
2-10 |
|||
KVVR |
Copper Conductor, PVC Insulated and Sheathed, Flexible Control Cable |
0.75, 1.0, 1.5, 2.5 |
4-61 |
Installed indoors where flexibility and movability are required |
KVVRP |
Copper Conductor, PVC Insulated & Sheathed, Braiding Shielded Flexible Control Cable |
0.75, 1.0, 1.5, 2.5 |
4-37 |
Installed indoors where flexibility shielding and movability are required |
KYJV |
Copper Conductor, XLPE Insulated and PVC Sheathed Control Cable |
1.0, 1.5, 2.5 |
2-61 |
Installed indoors, in cable ditches or pipes |
4, 6 |
2-14 |
|||
10 |
2-10 |
|||
KYJVP |
Copper Conductor, XLPE Insulated, Braiding Shielded, PVC Sheathed Control Cable |
1.0, 1.5, 2.5 |
2-61 |
Installed indoors, in cable ditches or pipes where shielding is required |
4, 6 |
2-14 |
|||
10 |
2-10 |
|||
KYJV22 |
Copper Conductor, XLPE Insulated, Steel-tape Armoured, PVC Sheathed Control Cable |
0.75, 1.0, 1.5, 2.5 |
4-61 |
Installed indoors, in cable ditches, pipes or underground. Be cable to withstand stronger external mechanicalforce |
4, 6 |
2-14 |
|||
10 |
4-10 |
|||
KYJVP2 |
Copper Conductor, XLPE Insulated, Copper tape Screened, PVC Sheathed Control Cable |
0.75 1.0 1.5 2.5 |
7-61 |
Installed indoors, in cable ditches or pipes where shielding is required |
4 6 |
4-14 |
|||
10 |
4-10 |
|||
KYJVR |
Copper Conductor, XLPE Insulated, PVC Sheathed Flexible Control Cable |
0.75 1.0 1.5 2.5 |
4-61 |
Installed indoors where flexibility and movability are required |
KYJVRP |
Copper Conductor, XLPE Insulated, Braiding Shielded, PVC Sheathed Flexible Control Cable |
0.75 1.0 1.5 2.5 |
4-37 |
Installed indoors where flexibility, shielding and movability are required |
Control Cable
Yiteng Cable Technology Hebei Co., Ltd
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250
Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);
Aerial Bundled Cable (ABC Cable);
Power cable,Electrical wire cable,
Armored cables,
Control cables,
Rubber insulated cables, PVC insulated wires and cables,
Battery cables,Instrument cables, Coaxial cables,Flat cables,
Welding cables,House wire,Special Cables etc.
Our Test Instrument
FAQ:
1.Q: Is your company a manufacturer or a trade company?
A: We are cable manufacturer.
2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, Hebei Province, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us
3. Q: What is your sample policy?
A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.
4.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end.
5. Q: I am very interested in your product, can you sent me your full catalog and pricing list?
A: We can select some popular products for you immediately. Please let us know your requirements so that we can send out the quotation to you.
Our Services
1.We guarantee to offer new advanced goods.
2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction, installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing,If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.
3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.
4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from
our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.
Notice:we can produce the product according to customer's requirment.Short delivery time and quotation at once.
