Flexible Copper/CCA Rubber Insulation Electric Welding Cable
Application
Welding cable suitable for the transmission of high currents from the welding apparatus to the welding tool. Suitable for flexible use under adverse conditions such as automobile manufacturing, conveyors and assembly lines. Also for use in machine tool and ship manufacturing.
Technical Information
Standard: IEC 60245
Conductor: Flexible Calss 5
Insulation: PVC or Rubber
Insulation Clour: black/orange
Cross Sectional area: from 10sqmm to 185sqmm
Operating Temperature: ≤85℃
Minimum Bending Radius:6 x Ø
Technical Data
Conductor Nominal |
Conductive Core |
Thickness of |
Average Outer |
200C Conductor |
Reference Weight |
||
Number/Diameter |
Min |
Max |
YH |
YHF |
|||
10 |
322/0.20 |
1.8 |
7.5 |
9.7 |
1.91 |
146 |
153.51 |
16 |
513/0.20 |
2.0 |
9.2 |
11.5 |
1.16 |
218.9 |
230.44 |
25 |
798/0.20 |
2.0 |
10.5 |
13.0 |
0.758 |
316.6 |
331.15 |
35 |
1121/0.20 |
2.0 |
11.5 |
14.5 |
0.536 |
426 |
439.87 |
50 |
1596/0.20 |
2.2 |
13.5 |
17.0 |
0.379 |
592.47 |
610.55 |
70 |
2214/0.20 |
2.4 |
15.0 |
19.5 |
0.268 |
790 |
817.52 |
95 |
2997/0.20 |
2.6 |
17.0 |
22.0 |
0.198 |
1066.17 |
1102.97 |
120 |
1702/0.30 |
2.8 |
19.0 |
24.0 |
0.161 |
1348.25 |
1392.55 |
150 |
2135/0.30 |
3.0 |
21.0 |
27.0 |
0.129 |
1678.5 |
1698.72 |
185 |
1443/0.40 |
3.2 |
22.0 |
29.0 |
0.106 |
1983.8 |
2020.74 |
Cable detailed information:
1. Cable working temperature should not exceed 65 degree
2. Cable have a certain extent of temperature resistance and oild resistance, fit to work outdoor
and smeary enviroment
3. Reach standard GB/T18380.1-2001 vertical flame test
4. When cable working in temperature 20 degree, the insulation between
Conductors above 50M .KM
Yiteng Cable Technology Hebei Co., Ltd
Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250
Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);
Aerial Bundled Cable (ABC Cable);
Power cable,Electrical wire cable,
Armored cables,
Control cables,
Rubber insulated cables, PVC insulated wires and cables,
Battery cables,Instrument cables, Coaxial cables,Flat cables,
Welding cables,House wire,Special Cables etc.
