Steel wire underground laying armoured cable
Specifications
steel wire underground laying armoured cable
1.Professional manufacturer
2.Reliable quality&competitive price
3.Fast delivery
Steel wire underground laying armoured cable
The PVC Insulated Power Cable and fire resistant cable are suitable for fixed laying in power transmission and distribution lines with A.C.50HZ and voltage rating of up to or including 6KV.
1. Conductors: copper or aluminum.
2. Both armored and non-armored type power cables are available.
3. Voltage rating: 0.6/1kV 3.6/6kV.
4. PVC or PE sheathed.
5. Number of cable cores: one core (Single core), two cores (Double cores), three cores,
Four cores (Four Equal-section-area cores or three equal-section-area cores and one smaller section area neutral core),
Five cores (Five equal-area cores or three equal-section-area cores and two smaller section area neutral cores).
6. Standards: Chinese national standard GB 12706 and GB 12666.6(equivalent to IEC 60502 and IEC 60331)
IEC, BS, DIN, ASTM, CSA, NFC, AS, GOST etc. Or other special characteristics as customers request.
Cable Types, Names and Applications
Type and Data
Cu Core |
AL Core |
Description |
Application |
VV |
VLV |
Cu(Al)Core PVC Insulated PVC Sheathed Power Cable |
For laying indoors, in ducts and tunnels, but unable to bear pulling force and pressure |
VY |
VLY |
Cu(Al)Core PVC Insulated PE Sheathed Power Cable |
|
VV22 |
VLV22 |
Cu(Al)Core PVC Insulated Steel Tape Armored PVC Sheathed Power Cable |
For laying indoors, in tunnels and directly in ground, able to bear pulling force and pressure |
VV23 |
VLV23 |
Cu(Al)Core PVC Insulated Steel Tape Armored PE Sheathed Power Cable |
|
VV32 |
VLV32 |
Cu(Al)Core PVC Insulated Fire Steel Wire Armored PVC Sheathed Power Cable |
For laying indoors, in wells and underwater, able to bear certain pulling force |
VV33 |
VLV33 |
Cu(Al)Core PVC Insulated Fire Steel Wire Armored PE Sheathed Power Cable |
|
VV42 |
VLV42 |
Cu(Al)Core PVC Insulated Thick Steel Wire Armored PVC Sheathed Power Cable |
For laying in wells and underwater, able to bear certain axial pressure |
VV43 |
VLV43 |
Cu(Al)Core PVC Insulated Thick Steel Wire Armored PE Sheathed Power Cable |
|
NH-VV |
NH-VLV |
Cu(Al)Core PVC Insulated PVC Sheathed Fire Resistant Cable |
For laying indoors, in ducts and tunnels, but unable to bear pulling force and pressure |
NH-VY |
NH-VLY |
Cu(Al)Core PVC Insulated PE Sheathed Fire Resistant Cable |
|
NH-VV22 |
NH-VLV22 |
Cu(Al)Core PVC Insulated Steel Tape Armored PVC Sheathed Fire Resistant Cable |
For laying indoors, in tunnels and directly in ground, able to bear pulling force and pressure |
NH-VV23 |
NH-VLV23 |
Cu(Al)Core PVC Insulated Steel Tape Armored PE Sheathed Fire Resistant Cable |
|
NH-VV32 |
NH-VLV32 |
Cu(Al)Core PVC Insulated Fire Steel Wire Armored PVC Sheathed Fire Resistant Cable |
For laying indoors, in wells and underwater, able to bear certain pulling force |
NH-VV33 |
NH-VLV33 |
Cu(Al)Core PVC Insulated Fire Steel Wire Armored PE Sheathed Fire Resistant Cable |
|
NH-VV42 |
NH-VLV42 |
Cu(Al)Core PVC Insulated Thick Steel Wire Armored PVC Sheathed Fire Resistant Cable |
For laying in wells and underwater, able to bear certain axial pressure |
NH-VV43 |
NH-VLV43 |
Cu(Al)Core PVC Insulated Thick Steel Wire Armored PE Sheathed Fire Resistant Cable |
Application conditions
1. The long-time permissible operation temperature of conductor shall not be higher than 70oC.
2. Conductor maximum short circuit (not more than 5 seconds) temperature shall not be higher than 160°C
3. The power cable is not limited by drop in level when being laid, and the ambient temperature shall not be lower than 0°C.
If so, the cable should be preheated.
4. Light weight, perfect bending properties, installed and maintained easily and conveniently.
5. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame.
