Help CenterElectrical Power Cable for Civil Use House Domestic Electrical Cable 0.3 0.5 0.75 1 1.5 2.5mm2
Related Products
-
Rated Voltage 450/750V and Below PVC Insulated Wire and CableUS$ 0.1 - 10MOQ: 100 Meters -
BVV BLV RVV Electric Wire and Cable PriceUS$ 0.1 - 10MOQ: 100 Meters
-
PVC Insulated Wire and CableUS$ 0.1 - 10MOQ: 100 Meters
-
High Temperature Resistant Silicone Rubber Leading WireUS$ 0.15 - 15MOQ: 500 Meters
-
BV BLV RV RVV BVVB BLVVB RVB RVS AVRS PVC Electric WiresUS$ 0.1 - 10MOQ: 100 Meters
electrical power cable for civil use house domestic electrical cable 0.3 0.5 0.75 1 1.5 2.5mm2electrical power cable for civil use house domestic electrical cable 0.3 0.5 0.75 1 1.5 2.5mm2electrical power cable for civil use house domestic electrical cable 0.3 0.5 0.75 1 1.5 2.5mm2electrical power cable for civil use house domestic electrical cable 0.3 0.5 0.75 1 1.5 2.5mm2electrical power cable for civil use house domestic electrical cable 0.3 0.5 0.75 1 1.5 2.5mm2
Description:
PVC insulated wire belong to the series of laying electric wires, which is mainly suitable for laying at the fixed places. It is widely used as connectors of drive, lighting, electric equipments, instrument and telecommunication equipments with rated voltage 450/750V or below. Part of the plastic wires are used at the equipment with AC rated voltage 300/300V or below.
Features:
1. The rated voltage U0 / U 3.6/6 KV
2. Cable conductor long-term work for 90 ° C temperature of cable
3. The smallest bending radius is six times the diameter of cable
4. Cable shall not be in the sunlight long exposure to
5. The bottom line of cable core must good grounding
Application:
Used in electronics, instruments and electronic equipment and automatic generation device with the power cord, line and signal transmission lines, concrete can be used for anti-theft alarm system, building talkback system, instrument and meter, and monitoring control such as the installation of surveillance.
Manufacturing Standards GB/T 12706-2008, IEC 60502-2
Specification
Type |
H05V-U, H07V-U, H07V-R, BS6004 6491X, BV, BVR |
Voltage Rate |
300/500V, 450/750V |
Range of Nominal cross section: |
0.75 mm2 ~ 630 mm2 |
Application |
These cables are used for general purpose, as building wire for power, lighting and control wire to electrical appliances, suitable for use in conduit and for fixed, protected installation. |
Standard |
IEC 60227, BS 6004, VDE0281, GB/T 5023, JB/T8734 |
Constructions |
Conductor: Class 1/2 Plain annealed copper wires, solid or stranded Insulation: PVC Core color: Red, Brown, Grey, Black, Blue, Green/Yellow or others on request |
Max. Operating Temperature |
70°C, can be 90°C,105°C as per requirement |
Packing |
100 meter/roll or as per requirement |
Production Capacity |
100 kilometer/ day |
Delivery time |
10~15 working days |
Remark |
The cable can be of flame retardance, fire resistance and other property |
H07V-R, H07V-U, 60227IEC01 (BV BLV (BV-90)450/750V)
|
Nominal section (mm2) |
Number/diameter of core (mm) |
Maximum outer diameter (mm2) |
Reference weight (Kg/km) |
Conductor resistance at 20°C ≤(Ω/km) |
||
copper |
aluminum |
aluminum |
copper |
|||
1.5(A) |
1/1.38 |
3.3 |
20.3 |
----- |
----- |
12.1 |
1.5(B) |
7/0.52 |
3.5 |
21.6 |
----- |
----- |
12.1 |
2.5(A) |
1/1.78 |
3.9 |
31.6 |
17 |
11.80 |
7.41 |
2.5(B) |
7/0.68 |
4.2 |
34.8 |
----- |
----- |
7.41 |
4(A) |
1/2.25 |
4.4 |
47.1 |
22 |
7.39 |
4.61 |
4(B) |
7/0.85 |
4.8 |
50.3 |
------ |
----- |
4.61 |
6(A) |
1/2.76 |
4.9 |
65 |
29 |
4.91 |
3.08 |
6(B) |
7/1.04 |
5.4 |
71.2 |
---- |
---- |
3.08 |
10 |
7/1.35 |
7.0 |
119 |
62 |
3.08 |
1.83 |
16 |
7/1.70 |
8.0 |
179 |
78 |
1.91 |
1.15 |
25 |
7/2.04 |
10.0 |
281 |
118 |
1.20 |
0.727 |
35 |
7/2.52 |
11.5 |
381 |
156 |
0.868 |
0.524 |
50 |
19/1.78 |
13.0 |
521 |
215 |
0.641 |
0.387 |
70 |
19/2.14 |
15.0 |
734 |
282 |
0.443 |
0.268 |
95 |
19/2.52 |
17.5 |
962 |
385 |
0.320 |
0.193 |
120 |
37/2.03 |
19.0 |
1180 |
431 |
0.253 |
0.153 |
150 |
37/2.25 |
21.0 |
1470 |
539 |
0.206 |
0.124 |
185 |
37/2.52 |
23.5 |
1810 |
666 |
0.164 |
0.0991 |
240 |
61/2.25 |
26.5 |
2350 |
857 |
0.125 |
0.0754 |
Welcome to our factory! Hope to get in touch with you!
| Factory Name | Yiteng Cable Technology HebeiCo.,Ltd |
| Location | Ningjin Town, Shijiazhuang, Hebei, China |
| Establishes in | 1994, 20 years' experience of producing kinds of cables |
| Export Office Location | Area1 Donghai Building, Shijiazhuang, Hebei, China |
| Our Main Cables Products |
Low Voltage Power Cable and Medium Voltage Power Cable with or without Armor(Armor Type:Steel Tape or Steel Wire) High Temperature Cable,Silicone Rubber Insulated Cable, Teflon Insulated Cable Mining Cable, Flexible Rubber Mining Cable, PVC and XLPE Aluminum Alloy Cable with/ without Armor and Interlock Shielded/ Screened Control Cable Computer Shielded Cable Flexible Rubber Cable Electrical Wires |
1. Any inquiries will be replied within 24 hours.
2. OEM/ODM available.
1) Printing your logo on the cable.
2) Printing your logo on the pull box, wooden drum according to your design
3) Any your idea on cable, packing box are available.
3. High quality, reasonable and competitive price, fast lead time.
4. Good after-Sale Service.
1) All products will have been strictly Quality Checked in house before packing.
2) All products will be well packed before shipping.
5. Faster delivery.
Sample order in stock, and 3-7 days for bulk production.
6. Payment
We can accept payment methods: L/C, T/T, Western Union,other payment can negotiation.
7. Package
Standard Export Wooden or Steel Drums or as per Customer's Requirement
8. ISO9001, ISO14001, CCC Certificates for Factory and Cable Products
