BOOST YOUR PRODUCTION AND IMPROVE YOUR QUALITYGAMUT Copy turning Face copying & Copy boring. GAMUT LATHE TRACERS are made by Graded Casting and have been Robustly constructed to take maximum cut with tool post and very sensitive and precise Copy-Valve to render trouble free longer service. GAMUT TRACER can be mounted at rear or front of a lathe machine and can be operated by semi-skilled personnel. Inspectiontime is drastically reduced and productionis increased by many times within accuracyof ±0.025mm when use good machining condition.
Technical Specification
MODEL |
1020 |
Stroke of Tracing Slide in mm |
200 |
Minimum centre Height from top of cross slide in mm |
|
Max.Dia of Round master in mm |
200 |
Max. length of rail in mm |
2000 |
Hydraulic Working Pressure in Kg/Cm² |
14 |
Pump Output in LT / Min |
14 |
Power Pack H.P. |
1.5 |
Theoretical Thrust in Kg |
470 |
Recommended tool shank in mm |
32x32 |
