Jumbo Roll Bottom Sealing Bag Machine With Heat Slitting Station

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Supply Ability 0 per Month

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Machine Type	Cutting Machine
Bag Type	Shopping Bag	Material	Plastic
Computerized	Yes	Place of Origin	China
Brand Name	Sing Siang Machinery	Model Number	AJ-1100-C4
Voltage	AC380V	Power(W)	4.0KW
Dimension(LWH)	7000* 1800*2000	Weight	2500KG
Certification	CE ISO9000	Warranty	One Year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

AJCG - 1100-C4 Bottom Sealing Bag Making Machine With Heat Silting Station

Type One : Tension Free Bottom Sealing Convertor

Type Two : Standard Bottom Sealing Convertor

Heat Slitting Blade

Web Guide Device

Special Features
	Servo Motor Driven, Efficient mechanical structure	Automatically stop when running out of film
	Fully Automatic, Large Screen , Easy to read, User Friendly	Automatically stop when film feeding blocks or bags jam
	Efficient output, less man power required	Automatically stop when The temperature not reaching setting.
	Digital setup, accurate registration, less waste	Automatically stop when the bags become super-imposed or overlapped
	Pleasant Cutting and Sealing, with high firmness
	Cutting Blade is very lasting, and easy for adjustment
	Cylinder Type Air Puncher, flexible, unlimited,replaceable, cost efficient

Optional Accessories

SPECIFICATION

MODEL

MAX.WIDTH

MAX.LENGTH

CONVERTING THICKNESS

ACCURACY LENGTH(m/m)

SPEED (PCS/MIN)

SERVO MOTOR/KW

HEATER

POWER REQUIRED

DIAMENSION
L * W * H (CM)

MACHINE WEIGHT

AJCG1100

1000 mm

1200 mm

0.002 - 0.02 mm

± 2

Max. 120

3.0 KW

2.4 KW

3.2 KW

700*160*200

1650 KG

Sing Siang Machinery Provide Great Diversity of Plastic Bag Making Machine
