DPP140C/250C AL/PL Blister Packing Machine

DPP140C/250C AL/PL Blister Packing Machine thumbnail-1
DPP140C/250C AL/PL Blister Packing Machine photo-1
US$ 1 - 11,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
sunhang
Model Number:
DPP140C/250C
Contact Supplier Request Quote Chat Now
Shanghai Sunhang Pharmaceutical Machinery Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name sunhang
Model Number DPP140C/250C
Dimension(L*W*H) 2800x800x1900 mm
Weight 1500KGS
Certification GMP
Condition New

Specifications

This machine is applied to Al-Pl, hard Al blister packing, such as capsules and tablets, sugar-coated tablets, small hard wares.

DPP140C/250C AL/PL Blister Packing Machine



Performance and Characteristics:

Variable Frequency Speed Regulating, PC Circuit Control Panel.

Adjustable travel adopts manipulator grip equipped with inching device, which has accurate synchronization.

With cylinder heat-sealing, the upper and lower checkers ensure the effect of heat-sealing.

Mould spout location is convenient for replacing mould.

Waste Automatic Recovery Device.

DA vibrating disk feeder, which is suitable for feeding breakable pills and milk, pills with dust on surface.

Main Technical Specifications:

Punching Frequency:20-40times/min

Punching Plate: 2-3plates/time

4plates/time(DPP250C)

Adjustable Scope of Travel: 30-120mm

Packing Efficiency: 4800-7200plates/hour

     4800-9600plates/hour (DPP250C)

Max Forming Area and Depth: 140x110x18mm

        245x112x30 mm (DPP250C)

Specifications of Packing Material:

Medical PVC: 150x0.25(0.15-0.5)mm

       250x0.25(0.15-0.5)mm (DPP250C)

          PTP: 150x0.02 mm

     250x0.02 mm (DPP250C)

Air-compressor: ≥0.15m3/ min; 0.22m3/ min (DPP250C)

Pressure: 0.5-0.7Mpa

Overall Size: 2200x750x1650mm

            2800x800x1900 mm (DPP250C)

Weight: 1500kg; 1500kg (DPP250C)

DPP140C/250C AL/PL Blister Packing Machine
