Weichai WD10/WD12/WP12 Series Marine Emergency Genset Generator 150KW-250KW

Weichai WD10/WD12/WP12 Series Marine Emergency Genset Generator 150KW-250KW thumbnail-1
Weichai WD10/WD12/WP12 Series Marine Emergency Genset Generator 150KW-250KW photo-1
US$ 3,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Weichai
Model Number:
WD10/WD12/WP12
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Weichai
Model Number WD10/WD12/WP12
Speed 1500/1800rpm
Frequency 50HZ/60HZ
Rated Voltage 400/440V

Weichai WD10/WD12/WP12 Series Marine Emergency Genset generator 150KW-250KW



Spectru



Generating set spectrum chart of WD10/WD12/WP12 series marine emergency diesel generator set (Marathon generator)



engine type Rated power
kW		 Diesel engine model Rated power of diesel enginekW intake mode Dimension
mm		 Weight
kg
CCFJ150Y-WI 150 WD615.68CD 170  turbocharged and intercooled 3110×1055×1756 2180
CCFJ180Y-WI 180 WD615.46CD 204  turbocharged and intercooled 3260×1055×1756 2260
CCFJ200Y-WI 200 WD618.42CD 235  turbocharged and intercooled 3030×1048×1564 2435
CCFJ220Y-WI 220 WD618.42CD 255  turbocharged and intercooled 3030×1048×1564 2435





Generating set spectrum chart of WD10/WD12/WP12 series marine emergency diesel generator set (Orchid electric generator)





engine type Rated power
kW		 Diesel engine model Rated power of diesel enginekW intake mode Dimension
mm		 Weight
kg
CCFJ150Y-WE 150 WD615.68CD 170  turbocharged and intercooled 2983×1055×1756 2350
CCFJ180Y-WE 180 WD615.46CD 204  turbocharged and intercooled 2983×1055×1756 2450
CCFJ200Y-WE 200 WD618.42CD 235  turbocharged and intercooled 2863×1048×1564 2500
CCFJ220Y-WE 220 WD618.42CD 255  turbocharged and intercooled 2863×1048×1564 2500





Generating set spectrum chart of WD10/WD12/WP12 series marine emergency diesel generator set (Stanford generator)



engine type Rated power
kW		 Diesel engine model Rated power of diesel enginekW intake mode Dimension
mm		 Weight
kg
CCFJ150Y-WU 150 WD615.68CD 170 turbocharged and intercooled 2892×1055×1756 2280
CCFJ180Y-WU 180 WD615.46CD      204 turbocharged and intercooled 2892×1055×1756 2330
CCFJ200Y-WU 200 WD618.42CD 235 turbocharged and intercooled 2860×1048×156 2535
CCFJ220Y-WU 220 WD618.42CD 255 turbocharged and intercooled 2860×1048×156 2535


Generating set spectrum chart of WD10/WD12/WP12 series marine emergency diesel generator set (Siemens generator)





engine type Rated power
kW		 Diesel engine model Rated power of diesel enginekW intake mode Dimension
mm		 Weight
kg
CCFJ150Y-WY 150 WD615.68CD 170 turbocharged and intercooled 2992×1055×1756 2400
CCFJ180Y-WY 180 WD615.46CD 204 turbocharged and intercooled 2992×1055×1756 2500
CCFJ200Y-WY 200 WD618.42CD 235 turbocharged and intercooled 2863×1048×1564 2535
CCFJ220Y-WY 220 WD618.42CD 255 turbocharged and intercooled 2863×1048×1564 2535





Dimensions




Installation dimension of WD10/WD12/WP12 series marine emergency diesel generator set (Marathon generator)



Model A1 A B W1 R D Dimension
L×W×H		 Weight  kg
CCFJ150Y-WI 280 565 850 918 10 25 3110×1055×1756 2180
CCFJ180Y-WI 280 565 850 918 10 25 3260×1055×1756 2260
CCFJ200Y-WI 400 700 850 918 8 25 3030×1048×1564 2435
CCFJ220Y-WI 400 700 850 918 8 25 3030×1048×1564 2435



Installation dimension of WD10/WD12/WP12 series marine emergency diesel generator set (Orchid electric generator)



Model A1 A B W1 R D Dimension
L×W×H		 Weight kg
CCFJ150Y-WE 280 565 850 918 10 25 2983×1055×1756 2350
CCFJ180Y-WE 280 565 850 918 10 25 2983×1055×1756 2450
CCFJ200Y-WE 400 700 850 918 8 25 2863×1048×1564 2500
CCFJ220Y-WE 400 700 850 918 8 25 2863×1048×1564 2500




Installation dimension of WD10/WD12/WP12 series marine emergency diesel generator set (Siemens generator)



Model A1 A B W1 R D Dimension
L×W×H		 Weight kg
CCFJ150Y-WY 330 600 850 918 10 25 2992×1055×1756 2400
CCFJ180Y-WY 330 600 850 918 10 25 2992×1055×1756 2500
CCFJ200Y-WY 400 700 850 918 8 25 2863×1048×1564 2535
CCFJ220Y-WY 400 700 850 918 8 25 2863×1048×1564 2535




Installation dimension of WD10/WD12/WP12 series marine emergency diesel generator set ( Stanford generator)



Model A1 A B W1 R D Dimension
L×W×H		 Weight kg
CCFJ150Y-WU 280 565 850 918 10 25 2892×1055×1756 2280
CCFJ180Y-WU 280 565 850 918 10 25 2892×1055×1756 2330
CCFJ200Y-WU 400 700 850 918 8 25 2860×1048×1564 2535
CCFJ220Y-WU 400 700 850 918 8 25 2860×1048×1564 2535




Note: The above generator set is subject to 1500rpm, 400V, 50Hz, IP23 generator set.





Intruction

WD10/WD12/WP12 Series Marine Emergency Genset adopts WD10/WD12/WP12 diesel engines as its power source and is equipped with brand name generator (Marathon, Siemens, Lan Dian, and Stanford). Its rotation speed reaches 1,500r/min or 1,800r/min and its power range is 150kW-250kW. CCS, ZY and BV classification certificates are provided upon request. Configuration Generators: famous brand generators such as Marathon, Siemens, Lan Dian, and Stanford are equipped. Insulation Grade is H. Emergency function: dual fuel start-up and emergency automatic start-up. Protection function: alarming systems will be activated once the rotation speed, oil pressure, water pressure or oil temperature reaches the limit. Main features Excellent performance: This series emergency Genset boasts advantages of compact structure, high power, high reliability, easy operation and maintenance. Safe and reliable generator: This series Genset selects brand-name generator, including Marathon, Siemens, Lan Dian and Stanford, etc. with insulation grade of H and protection grade of IP23. High economic performance: The overall cost of the Genset is relatively low. It boasts high economic performance and thermal efficiency. Its fuel consumption curve is comparatively flat with comparatively low fuel consumption even under low load. Optional configuration Start-up: electric / gas motor, electric / spring motor Speed adjustment: electronic speed governor Instrument: local / remote display / remote control Generator: Marathon / Siemens / Lan Dian / Stanford / Others Coolant heater Lubricant heater Voltage: 400V/440V Frequency: 50Hz/60Hz Silencer / flame extinguishing silencer Unrestricted service Classification certificates: CCS/ZY/BV
