Weichai WD12 Series of Marine Diesel Engine 140-240Kw

Weichai WD12 Series of Marine Diesel Engine 140-240Kw thumbnail-1
Weichai WD12 Series of Marine Diesel Engine 140-240Kw photo-1
US$ 5,000 - 50,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China Mainland
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Diesel
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 1900*774*1180mm
Product Description

 Born from WD615C, Weichai WD12 (WD618) series high power marine diesel engine boasts a number of strengths, including increased strokes, compact structure, small size, light weight, low speed & high torque, high performance per liter and high torque reservation, low noise, high reliability and durability, as well as easy maintenance. Equipped with double-circulation water-cooling system with the interior circulation using fresh water to cool the engine while the exterior circulation using double-pipe heat exchanger to cool fresh water by seawater, this series products enjoy longer durability.



The WP4 series have passed the International Association Classification Society Certificates of CCS,ZY,ABS, GL,BV,DNV ,RS and LR.



Weichai WD12 Series of Marine Diesel Engine 140-240Kw

Product Application

 This series are ideally used on river transport ships, fishing boats and public vessels.



Main Technical Data



Item Unit Engine type
WD615.C-24 WD615.C-23 WD615.C-22 WD615.C-21 WD615.C-25
intake mode Turbocharged and intercooled
number of cylinders 6
bore X stroke 126×130
displacement L 9.726
rated power KW 140 160 176 190 205
rated speed r/min 1500 1500 1500 1500 1500
min. fuel oil consumption g/(KW.h) ≤220
lub oil and fuel consumption ratio % ≤0.8
cooling mode   sea and fresh water duel-circulation cooling system
start mode electric start
net weight  kg 1056
rotation direction of crankshaft (seen from the free end) clockwise
dimension length 1900mm
  width 774mm
  height 1180mm



Item Unit engine type
WD
615.67
C		 WD
615.46
C-11		 WD
615.46
C-12		 WD
615.68
C		 WD
615.46
C
intake mode   turbocharged and intercooled
number of cylinders 6
bore X stroke 126×130
displacement L 9.726
rated power KW 176 205 230 205 220
rated speed r/min 1800 1800 1800 2100 2100
fuel consumption @ rated power g/(KW.h) ≤220 ≤220 ≤220 ≤215 ≤220
lub oil and fuel consumption ratio % ≤0.8
cooling mode   sea and fresh water duel-circulation cooling system
start mode electric start
net weight  kg 1056
rotation direction of crankshaft (seen from the free end) clockwise
dimension length 1900
mm		 1440
mm		 1440
mm		 1900
mm		 1440
mm
  width 774
mm		 774
mm		 774
mm		 774
mm		 774
mm
  height 1180
mm		 1400
mm		 1400
mm		 1184
mm		 1400
mm



Item Unit engine type
WD615.C
-28		 WD615
.61C		 WD615
.61C-2		 WD615
.46C-8		 WD615
.46C-1
intake mode turbocharged turbocharged turbocharged  turbocharged and intercooled  turbocharged and intercooled
number of cylinders 6
bore X stroke 126×130
displacement L 9.726
rated power KW 125 140 147 230 240
rated speed r/min 1500 1800 2100 2100 2100
fuel consumption @ rated power g/(KW.h) ≤220 ≤220 ≤220 ≤220 ≤220
lub oil and fuel consumption ratio % ≤0.8
cooling mode   sea and fresh water duel-circulation cooling system
start mode electric start
net weight  kg 1056 1018 1018 1056 1056
rotation direction of crankshaft (seen from the free end) clockwise
dimension length 1900
mm		 1620
mm		 1618
mm		 1990
mm		 1440
mm
  width 774
mm		 774
mm		 774
mm		 774
mm		 774
mm
  height 1180
mm		 1180
mm		 1120
mm		 1180
mm		 1400
mm
