CHD316 Series of Marine Diesel Engine Developed From Gernany 616 Diesel Engine

CHD316 Series of Marine Diesel Engine Developed From Gernany 616 Diesel Engine thumbnail-1
CHD316 Series of Marine Diesel Engine Developed From Gernany 616 Diesel Engine photo-1
US$ 50,000 - 100,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China Mainland
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Diesel
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 1820*1360*1360*(mm)
Product Description

 CHD316 Series Diesel Engine are developed from Germang 616 Diesel Engine.Up to now, they have got the International Association Classification Society Certificates of CCS,ZY,ABS, GL,BV,DNV and LR, Having been exported to more than 50 countries and regions in Asia, Europe, Africa, America and Oceania.



Main features of CHD316 Diesel Engines: Good economy, Good startability and speeding-up performance, High reliability, Long service life, Good performance at low load, Easy maintenance and Less cost of maintenance, Compact structure, Small size, Light weight; they can meet the emission requirement of IMO Nox.



Main Technical Data



Model CHD316-V8 CHD316-V12 CHD316-V16
Bore/Stroke 132mm/160mm
Cylinder Arrangement V-60°
Number of Cylinder 8 12 16
Unit Cylinder Volume 2.19dm³
Total Cylinder Volume 17.52dm³ 26.28dm³ 35.04m³
Dimension 1820*1360*1360 (mm) 2250*1360*1360 (mm) 2585*1320*1390 (mm)
Dry Weight 1550 kg 2420 kg  3450 kg
Compression Ratio 15:1
Rated Power 624kw-1325kw
Max.Combustion Pressure 17Mpa
Min.Steady Speed 650r/min
Ignition Speed 115r/min
Direction Anti-clockwise rotation (from flywheel end)
Lub. Oil Combustion ≤1g/kw·h
Emissions IMO Tier II
Product Application

 CHD316 series are not only widely used in ship field such as Military equipment, Commercial cargo ship, Passenger ship, Tourist ship, Working ship, Fishing ship and High-speed vessel but also in other fields such as Petroleum industry, Coal industry, Construction,Mining, Nuclear power station, Hydropower station, Emergency/fire pump and Special vehicles.





Factory Workshop

 CHD316 Series of Marine Diesel Engine developed from Gernany 616 Diesel Engine

Packaging & Shipping

 CHD316 Series of Marine Diesel Engine developed from Gernany 616 Diesel Engine
