Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > KAMA 18.75kva THREE Phase Small Diesel Generator Open-frame Type
KAMA 18.75kva THREE Phase Small Diesel Generator Open-frame Type
US$ 300 - 2,000
MOQ: 1 Acre
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KAMA
Model Number:
KDE 20E3
Payment & Shipping
Payment Methods:
Port of Shipment:
Shaihai or ther port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KAMA 18.75kva Single Phase Small Diesel Generator Open-frame TypeUS$ 300 - 2,000MOQ: 1 Set -
KAMA 15.625kva Three Phase Small Diesel Generator Silent TypeUS$ 600 - 2,600MOQ: 1 Unit
-
KAMA 15.625kva Single Phase Small Diesel Generator Silent TypeUS$ 500 - 2,500MOQ: 1 Unit
-
KAMA 15.625kva Three Phase Small Diesel GeneratorUS$ 500 - 2,000MOQ: 1 Set
-
KAMA 15.625kva Single Phase Small Diesel Generator Open-frame TypeUS$ 100 - 1,500MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
KAMA
Model Number
KDE 20E3
Speed
3000/3600rpm
Frequency
50HZ/60HZ
Rated Power
15KW
Rated Voltage
400V/230V
Rated Current
21.7A
KAMA 18.75kva THREE phase small diesel generator Open-frame type
Main Data
| Rated frequency(Hz) | 50 60 | |
| Rated voltage(V) | 400/230 400/230 | |
| Rated current(A) | 21.7 21.7 | |
| Rated output power(KW) | 15 15 | |
| Max output power(KW) | 16.5 16.5 | |
| Rated otation speed(rpm) | 3000 3600 | |
| Power factor(cos) | 0.8(Applied to KVA) | |
| Phase number | Three phase | |
| Excitation mode | Self-excitation and constant voltage(AVR) | |
| Overall dimension(LxWxH)[mm(in)] | E:1270x830x940(50.00x32.68x37.01)T:1660x730x1020(65.35x28.74x40.16) | |
| Dry weigt[kg(ibs.) | E:360(792),T:455(1001) | |
| Structure type | E:Open-frame type T:Silent type | |
| Engine model | KM380G | |
| Rated power[kW(Hz)/rpm] | 21(28.56)/3000.21(28.56)/3600 | |
| Engine type | Three cylinder,in-line,water-cooled,4-stroke,direct injection,diesel engine | |
| Bore*stroke[mm(in)] | 80x90(3.15x3.54) | |
| Compression ratio | 18:1 | |
| Total displacement[L(cu.in)] | 1.357(82.81) | |
| Fuel consumption at full load[g(ml)/kW.h] | <245(291) | |
| Starting system | 12V electric starter | |
| Fuel | 0#(summen)-10#(winter)light diesel oil | |
| Cooling system | Forced water-cooled circulation | |
| Lube Capacity[L(gal.)] | 38(8.36) | |
| Lube | LECD grade 15W40 |
MODEL KDE20E3
