Help CenterDouble Motors Trommel Screen SYZX Rotary Sieve
Related Products
-
Linear Vibrating Sieve Sand ScreenerUS$ 2,399 - 2,899MOQ: 1 Set -
ISO,CE Mineral Separator Classifier ShakerUS$ 2,399 - 2,899MOQ: 1 Set
-
High Screening Efficiency Linear Vibrating Screen For Vibrating Screen Separator for Powder, Granule and LiquidUS$ 3,183 - 3,519MOQ: 1 Set
-
Circle Mould Materials Screening MachineUS$ 1,999 - 3,999MOQ: 1 Set
-
China Dia1500 Vibration Screen for Sale;dewatering ScreenUS$ 1,999 - 3,535MOQ: 1 Set
Specifications
trommel screen SYZX rotary sieve1.double motors
2.large treatment capacity
3.SUS304/carbon steel
4.ISO,CE,RoHs
Double motors trommel screen SYZX rotary sieve
Production Introduction
Double motors trommel screen SYZX rotary sieve is our company’s new screen device especially for screening the materials in the quarry, which adopted the vibrating of tube eccentric shaft to adjust theamplitude. And it features stable structure, strong vibrating force,high screening efficiency, low vibrating voice, firmly durable,long service life and easy maintenance, and safe operation, etc. Besides, it is widely used in building materials, transportation, energy, coal preparation, cement, mine, electricity and chemical industries, especially for classifying coal, limestone, broken stone, grit,metal or non-metal ore and the other materials.
Working principle SY
Double motors trommel screen SYZX rotary sieve mainly consists of the eccentric block vibrator, screen box, motor, and supportive device.Through the flexible coupling, the motor drives the eccentric block of the vibrator at high rotary speed, generating the centrifugal force, and then causing the screen box do circular movement .After that, the materials in the slope screen surface will be cast continuously by the force generated from the screen box, then realizes the purpose of classifying.
Features SY
1.driven by double motors, synchronous transmission;
2.main vibrating spring is made of rubber;
3.motor drive the main bearing to rotate via coupling with rubber type element in the side of screen box;
4.simple structure, convenient maintenance, do not produce coarse vibration and noise during operation,low malfunction;
5.long use life motor,high work efficiency;
6.easy to input material and change sieves convinently.
Application SY
Technical Paraments SY
Model |
Nominal Size(mm) |
Amplitude(mm) |
Layer Number |
Power(kw) |
Overall Dimensions |
||
SYZX520 |
500×2000 |
3-4.5 |
1-6 |
2×(0.4-0.75) |
2740 |
870 |
1440 |
SYZX525 |
500×2500 |
3-4.5 |
1-6 |
2×(0.4-0.75) |
3240 |
870 |
1440 |
SYZX530 |
500×3000 |
3-4.5 |
1-6 |
2×(0.4-0.75) |
3740 |
870 |
1440 |
SYZX1020 |
500×2000 |
3-4.5 |
1-6 |
2×(0.4-0.75) |
2740 |
1370 |
1440 |
SYZX1025 |
500×2500 |
3-4.5 |
1-6 |
2×(0.4-0.75) |
3240 |
1370 |
1440 |
SYZX1030 |
500×3000 |
3-4.5 |
1-6 |
2×(0.4-0.75) |
3740 |
1370 |
1440 |
Machine Design SY
Any calls / letter inquiries about vibrating sieve shaker information, please also provide the following information in your enquiry to make prompt and accurate reply.
(1) Raw materials needed to deal with: the name, size, structure, the proportion of water, viscosity, temperature or others
(2)The purpose of: grade, filter, edulcoration
(3)Handling capacity: kg / hour or liter / hr
(4)Screen Size (mesh or mm)
(5)Job running time
(6)Other special requirements, such as: temperature, resistance and other media.
