Fire Retardant Steel Armoured Pe Electrial Control Cables
1.Steel armoured electrial control cable specification
Generally speaking, there are two ways of copper wires braided screen and copper tape wrapped screen for control cables, however, copper wires braided screen has stable structure, the effect of screen won’t change with the cable bending or appearance factors etc, but also doesn’t have influence on cables’ flexibility, braiding density can reach over 80%, besides,copper tape wrapped screen percentage of coverage can reach up to 100%.
Plastic PVC Insulated Screened control Cables are used for rated voltage up to and including 450/750V.
The longterm operating temperature of PVC insulation cable conductor should be lower than 70°C,and that of XLPE insulation should be lower than 90°C.
The installing ambient temperature of cables shouldn’t be lower than 0°C,the Min. bending radius of installing is 6 times of the outer diameter.
2.Unarmored control cables
Such unarmored control cables are suitable for laying indoors and in the electrical cabinets, however, the cables can’t bear larger external mechanical forces.
PVC sheath has stable property and excellent chemical corrosion protection characteristics, also with the features of non-fire propagation and non-water absorption, which greatly ensure the cables’ service life.
3.Control cables with steel wires armored
Steel wires armored control cables can endure certain mechanical tension, which are widely suitable for highlevel difference environment, also can be installed vertically .Cables with screen have good shielding and anti-interference performances.
| U0/U | 450/750V |
| Standard | GB/T9330-2008 |
| Not exceeding 70°C for general types | |
| Max.Working temperature | Not exceeeding 90°C for XLPE |
| Not exceeding 105°C for the heat resistant | |
| Conductor | Copper |
| Insulation | PE |
| Screening | As you aquirement |
| Armoring | As you aquirement |
| Sheath | As you aquirement |
| Cross section area | As you aquirement |
| Cores | Multicore |
| Packing | Wooden drum |
| Certification | ISO9001, ISO14001, IEC, CCC |
| Remark | As you aquirement |
Certifications Required:
1.When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
2.How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
3.How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days.
4.What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
