Home > Products > New Products > 100% New in Stock 150Kva Cummins Generator, Powered by Cummins 6BTAA5.9-G2 Engine

100% New in Stock 150Kva Cummins Generator, Powered by Cummins 6BTAA5.9-G2 Engine

Name: 100% New in Stock 150Kva Cummins Generator, Powered by Cummins 6BTAA5.9-G2 Engine
Brand: 150kva Cummins generator
Availability: InStock

FOB Price

US$ 10,500 - 13,500 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	150kva Cummins generator
Model Number	6BTAA5.9-G2	Output Type	AC Three Phase
Speed	1500rpm/min	Frequency	50Hz
Rated Power	150Kva	Rated Voltage	110V~600V
Rated Current	216A

Product Description

Specifications

150kva Cummins generator, powered by Cummins 6BTAA5.9-G2 engine
Stamford alterantor
Deepsea control panel
High quality

150Kva Cummins generator (Engine model: 6BTAA5.9-G2)

Main technical data

Cummins engine-6BTAA5.9-G2

Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

24V DC start motor;

Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;

Equipped with industrial silencer and flexible exhaust hose;

Equipped with CHINT MCCB circuit breaker;

Designed to Comply with ISO8528/GB2820;

Powered by Cummins engine,Controlled by Deepsea panel

Voltage

Phase

P.F

(COS)

Output

(KVA)

400/230V

0.8

150

Remark

60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements.

Engine

Cummins 150kva diesel generator engine data:

Engine Model	6BTAA5.9-G2
Number of Cylinders	6 cylinders, Vertical in line
Cycle	4 stroke
Aspiration	Turbocharged and after water cooled
Bore×Stroke	102mm x120mm
Displacement	5.9L
Compression ratio	17.5:1
Prime Power/Speed	120KW / 1500rpm
Standby Power/Speed	130KW / 1500rpm
Speed Governor	electrical
Cooling System	Forced water cooling cycle
Steady speed droop	≤1%
Total lubrication system capacity	16.4L
Coolant capacity (engine only)	9.1L
Fuel Consumption at 100% Load	208g/kw.h
Starter Motor	DC24V,
Alternator	AC24V

Alternator

Alternator brand	Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
Prime power	150Kva
Frequency/speed	50HZ/1500rpm (60Hz/1800rpm)
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23

Control panel

The control module gives digital readouts of:

Generator voltage;

Output frequency;

Engine speed;

Battery voltage;

Engine hours run.

The control module has indicators for failure

information:

Overspeed/underspeed,

Emergency stop

Low oil pressure;

High water temperature

Failure to start

Battery charger failure

Automatic shutdown occurs under:

Low engine oil pressure;

High engine water temperature;

Overspeed/underspeed;

Failure to start after three attempts.

Pictures FYI

150Kva Cummins open diesel generator

150Kva Cummins silent diesel generator
