Home > Products > New Products > 75Kva Cummins Genset, Powered by Cummins 6BT5.9-G2 Engine

75Kva Cummins Genset, Powered by Cummins 6BT5.9-G2 Engine

Name: 75Kva Cummins Genset, Powered by Cummins 6BT5.9-G2 Engine
Brand: 75kva Cummins genset
Availability: InStock

FOB Price

US$ 7,000 - 10,500 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	75kva Cummins genset
Model Number	6BT5.9-G2	Output Type	AC Three Phase
Speed	1500rpm/min	Frequency	50Hz
Rated Power	75Kva	Rated Voltage	110V~600V
Rated Current	108A

Product Description

Specifications

75kva Cummins genset, powered by Cummins 6BT5.9-G2 engine
Stamford alterantor
Deepsea control panel
High quality

75Kva Cummins genset (Engine model: 6BT5.9-G2)

Main technical data

Cummins engine-6BT5.9-G2

Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

24V DC start motor;

Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;

Equipped with industrial silencer and flexible exhaust hose;

Equipped with CHINT MCCB circuit breaker;

Designed to Comply with ISO8528/GB2820;

Powered by Cummins engine,Controlled by Deepsea panel

Voltage

Phase

P.F

(COS)

Output

(KVA)

400/230V

0.8

Remark

60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements.

Engine

Cummins diesel generator power capacity

Engine Model	6BT5.9-G2
Number of Cylinders	6 cylinders in line
Cycle	4 stroke
Aspiration	Turbocharged and after water cooled
Bore×Stroke	102mm x120mm
Displacement	5.9L
Compression ratio	17.5:1
Prime Power/Speed	86KW / 1500rpm
Standby Power/Speed	92KW / 1500rpm
Speed Governor	Electrical
Cooling System	Forced water cooling cycle
Steady speed droop	≤1%
Total lubrication system capacity	16.4L
Coolant capacity (engine only)	9.1L
Fuel Consumption at 100% Load	208g/kw.h
Starter Motor	DC24V,
Alternator	DC24V

Alternator

Alternator brand	Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
Prime power	75Kva
Frequency/speed	50HZ/1500rpm (60Hz/1800rpm)
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23

Control panel

The control module gives digital readouts of:

Generator voltage;

Output frequency;

Engine speed;

Battery voltage;

Engine hours run.

The control module has indicators for failure

information:

Overspeed/underspeed,

Emergency stop

Low oil pressure;

High water temperature

Failure to start

Battery charger failure

Automatic shutdown occurs under:

Low engine oil pressure;

High engine water temperature;

Overspeed/underspeed;

Failure to start after three attempts.

Pictures FYI

100Kva Cummins silent diesel generator

100Kva Cummins silent diesel generator (Packing)
