11kV Porcelain High Voltage Lightning Arrester

11kV Porcelain High Voltage Lightning Arrester thumbnail-1
11kV Porcelain High Voltage Lightning Arrester photo-1
US$ 14.5 - 16.5 MOQ: 3 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SR
Model Number:
Y5W-11,Y10W-11
Contact Supplier Request Quote Chat Now
Wenzhou Shuguang Fuse Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo etc
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name SR
Model Number Y5W-11,Y10W-11

Specifications

Metal Oxide lightning arrester
1. rated voltage: 11kV
2. porcelain housing
3. certificaat: ISO 9001: 2008



Key Specifications/Special Features:


Type:Y5C-11,Y10C-11
Rated voltage r.m.s: 11KV
Continuous operating voltage r.m.s: 9.3KV
1/5u s steep current residual voltage(KV): 36.4(5kA), 38.4(10kA)
8/20u s lighting impulse residual voltage(kV): 32.5(5kA), 34.2(10kA)
30/60u s switching impulse residual voltage(kV): 24.7 (5kA), 25.7 (10kA)
2ms rectangular current(A): 100(5kA), 250(10kA)
4/10u s high current impulse(kA): 65(5kA), 100(10kA)
Insulation housing withstand voltage(kV)
Lightning impulse:75
Power frequency:30
Creepage distance(mm): 460
