15 Inch Two Pints P-Cap Open Frame Touch Monitor With Handwriting for ATM, VTM, Interactive Kiosk, Gaming, HMI

Model Number

GT-TMO15001

Name

15"Open Frame touch monitor

Structure

Open frame iron box,  black color in front ,white sliver on the back

Display Type

Full New 15"Active matrix TFT-LCD  4:3

Active area

305×228(mm)

Resolution

1024×768@60Hz

Support color

16.7M

Brightness (Typ.)

Display Panel :250cd/m2(Typ.)

After Add the touch screen :230cd/m2(Typ.)

Response time (Typ.)

16ms(Typ.)

Pixel

0.297*0.297mm

Viewing Angle(Typ.at CR>10))

Horizontal(L/R):75°/75°

Vertical(Up/Down):65°/65°

Contract (Typ.)

450:1(Typ.)

Video input

Mini D-Sub15pin  VGA,DVI

Scan Frequency(L/F)

Horizontal:30~80KHz ,vertical: 56.3~75Hz

Power Input

External connect power adapter,Support AC 100 ~ 240V,50 ~ 60Hz,DC12V-3A

Environment

Operate temperature :0 ~ 50°C

Storage temperature :-20 ~  60°C

Operating humidity:20% ~ 80%

Storage humidity:10% ~ 90%

Mean Time Between Failure (MTBF)

30,000 hours

Backlight working life(Typ.)

50,000 hours

Power consumption

max19W

OSD Control

Button :POWER,MENU,AUTO,UP,DOWN

Installation method

Install 75*75 mm & 100*100mm VESA hole on the back,aside hole also can be used

Touch screen Type

4/5 wire resistive ,SAW,IR Optical touch screen can be selected

Touch life

Over 5,00 million times

Surface hardness of the touch screen

Equal with glass,7mosh

Touch object

Finger or touch pen

Touch screen interface

USB or RS232 interface

Touch screen response time

10ms

Touch force

30g

Display size

mm

Package size

mm

Weight(N.t/W.t)

Kg/Kg

Certification

FCC,CE,CCC,RoHS

Warranty

Display panel 3yesrs,touch screen 3year

Note: LCD display parameter will be changed according to the LCD brand and model
