Specifications
All in one touch monitorHD resolution high contrast ratio fast response wide angle
adapted with worse environment
VGA
Product specifications and parameters:
GreenTouch Open Frame Monitor adopt new A + LCD screen produced by international companies, designed withall-plasticergonomic shell, and new energy-saving drive board . Special for desktop anddesktop public service inquiry system,POS systems, hotel reception, self-service, industrial manufacturing, information systems and other interactive touch applicationsenvironmental design .
Open frame touch monitor specifications and parameters:
| Model Number | GT-TMO185A |
| Display type | TFT LED panel |
| Screen Ratio | 16:9 |
| Resolution | 1366X768 |
| Active area | 410X233(mm) |
| Brightness | 300cd/m2 |
| Contrast Ratio | 1000:1 |
| Support color | 16.7M |
| Response time | 8ms |
| Pixel Pitch | 0.297x0.297mm |
| Viewing Angle | Horizontal(L/R):85°/85° Vertical(Up/Down):80°/80° |
| Video input | DVI,VGA |
| Scan Frequency | Horizontal:30~80KHz ,Vertical: 56.3~75Hz |
| Power Input | Support AC 100 ~ 240V,50 ~ 60Hz,DC12V-3A |
| Environment | Operating temperature:0 to 50°C Storage temperature:-20 to 60°C |
| Operating humidity:20% to 80% Storage humidity:10% to 90% | |
| Mean Time Between Failure (MTBF) | 30,000 hours |
| Backlight working life(Typ.) | 50,000 hours |
| Touch screen Type | 4/5 wire resistive,SAW,IR Optical touch screen (can be selected) |
| Touch life | Over 5,00 million times |
| Touch object | Finger or touch pen |
| Touch screen interface | USB or RS232 interface |
| Power consumption | Max 25W |
| Certificates | CE, FCC |
| Button | POWER,MENU,AUTO,UP,DOWN |
| Warranty | 1 year |
Open frame touch monitor pictures
Open frame touch monitor Certificates
Open frame touch monitor shipping and payment
And also accept by Sea ,Air .or sending with your own forwarder
Open frame touch monitor, why choose ours?
1.Professional manufacturer in R&D, manufacturing, marketing and service of TOUCH SCREEN for 8 years.
2.High quality certificate (CE,ROHS,FCC) Our products have aging test at least for a continuous 48-72hours before being deliveried.
3.Product warranty for 1-4 years.
4.Sufficient stock for your urgent demand. 5.Within 12 hours reply guarantee.
Open frame touch monitor company show
Hope to set up friendly business relationship with all of you.Your comments on our products and any information from your market will be highly appreciated.
(If I'm off line, would you send a massage to me or email please ? i will reply within 12hours .)
