Concrete Block Clamp
1.Handle solid,regular cubic goods under normal temperature
2.Used in construction material,
Concrete Block Clamp
1.Used for hadlling various types of solid, regular cubic goods under normal temperature
Forklift Block Clamp can efficiently and safely handle various types solid, regular cubic goods under normal temperature.
2.Widely used in construction material, metallurgy industries
Forklift block clamp widely used in construction material, metallurgy industries for hadling concrete blocks, cement bricks, carbon cubes, etc. The high structural strength and durability ensure the safe, productive application and long service life.
3. Features
-Proven durable T-beam arm aluminum frame construction
-Superior arm-side bearing for extended service life
-Regenerative hydraulic valving for optipal arm speed
-Durable contact pads, reliable clamping
-Excellent driver visibility
4. Various mounting class available
| Name | Capacity/ Load Center (kg@mm) |
Type |
Mounting Class |
Opening Range E (mm) |
Arm Height H (mm) |
Arm Length L (mm) |
Frame Width B (mm) |
Overall Height(mm) | Weight(kg) | Effective Thickness (mm) |
Horizontal Center of Gravity (mm) |
| Concrete Block Clamp | 2700/500 | CKS30D-001A | II | 290-1610 | 128 | 1100 | 1016 | 710 | 500 | 145 | 220 |
| 2700/500 | CKS30D-002A | II | 290-1610 | 242 | 1100 | 1016 | 710 | 550 | 145 | 220 | |
| 2700/500 | CKS30D-003A | II | 290-1610 | 128 | 1000 | 1016 | 710 | 490 | 145 | 211 | |
| 2700/500 | CKS30D-004A | III | 290-1610 | 128 | 1100 | 1016 | 710 | 500 | 152 | 220 | |
| 2700/500 | CKS30D-005A | III | 290-1610 | 242 | 1100 | 1016 | 710 | 550 | 152 | 220 | |
| 2700/500 | CKS30D-006A | III | 290-1610 | 128 | 1000 | 1016 | 710 | 490 | 152 | 220 | |
| 2700/500 | CKS30D-007A | III | 290-1610 | 242 | 1400 | 1016 | 710 | 650 | 152 | 250 |
5.Options
-Custom opening ranges
-Custom pad sizes
-Load backrests
7. Application
Please contact me if you need our help!Thank you and best regards!
,
