Forklift Sideshifter
- 1000 Set / Sets per Month
- Xiamen
- T/T
- Hand tool parts castings
- OEM/ODM steel air tool parts / needle bar bushing
- air chuck,air accessory,pneumatic tool parts
- Air conditioner parts develop stamping tooling die
- Investment Casting Pneumatic tools accessories with Stainless Steel and Alloy Steel Materials
- customized high quality Milling Tools
Product Details
Brand Name: | WONTONNE | Place of Origin: | China | Model Number: | GC Series |
Product Description
GC Series sideshifters are disigh to improve the flexibility and moving efficiency when handling and stacking.Products Introduction:
WONTONNE GC Sideshifter is designed to improve the flexibility and moving efficiency when handling and stacking. We typically supplied in 2500Kg to 3500Kg capacities to suit your operations, though others are available on request.
WONTONNE GC Sideshifter are greatly appreciated in the markets based on the high quality and reliable performance.
Products Display:
1.Intergrate cylinder and side shifter frame into a componpent, saving room and widening the view.
2. Easy installed, directly connected to fork carriage.
3. Double-headed rod cylinder, keep the same thrust force and speed on both sides of cylinder.
4. The lower bearings used wear-resistant nylon-material to ensure smoothly move.
5. Highly efficiency, easy maintenance and operation.
Test
Every sideshifter from WONTONNE must pass a series of strict test before selled.
Packing
Every sideshifter from WONTONNE must be packed very carefully before shipment.
Speficication:
Capacity @ Load Center | New Catalog Order No. | Mounting Class | Minimum Truck Carriage Width(mm) | Carriage Width(mm) | Vertical Center of Gravity(mm) | Weight(kg) | Effective Thickness(mm) | Horizontal Center of Gravity(mm) |
2500@600 | CYQ25F-B001-920 | 2 | 895 | 920 | 226 | 49 | 62 | 27 |
2500@600 | CYQ25F-B001-970 | 2 | 895 | 970 | 226 | 50.5 | 62 | 27 |
2500@600 | CYQ25F-B001-1020 | 2 | 895 | 1020 | 226 | 52 | 62 | 27 |
2500@600 | CYQ25F-B001-1040 | 2 | 895 | 1040 | 226 | 53 | 62 | 27 |
2500@600 | CYQ25F-B001-1070 | 2 | 1040 | 1070 | 226 | 54 | 62 | 27 |
2500@600 | CYQ25F-B001-1100 | 2 | 1040 | 1100 | 226 | 55 | 62 | 27 |
2500@600 | CYQ25F-B001-1200 | 2 | 1040 | 1200 | 226 | 58 | 62 | 27 |
2500@600 | CYQ25F-B002-920 | 2 | 895 | 920 | 226 | 50 | 62 | 27 |
2500@600 | CYQ25F-B002-970 | 2 | 895 | 970 | 226 | 51.5 | 62 | 27 |
2500@600 | CYQ25F-B002-1020 | 2 | 895 | 1020 | 226 | 53 | 62 | 27 |
2500@600 | CYQ25F-B002-1040 | 2 | 895 | 1040 | 226 | 54 | 62 | 27 |
2500@600 | CYQ25F-B002-1070 | 2 | 1040 | 1070 | 226 | 55 | 62 | 27 |
2500@600 | CYQ25F-B002-1100 | 2 | 1040 | 1100 | 226 | 56 | 62 | 27 |
2500@600 | CYQ25F-B002-1200 | 2 | 1040 | 1200 | 226 | 59 | 62 | 27 |
3500@600 | CYQ35F-C001-1070 | 3 | 935 | 1070 | 293 | 66 | 64 | 29 |
3500@600 | CYQ35F-C001-1100 | 3 | 935 | 1100 | 293 | 67 | 64 | 29 |
3500@600 | CYQ35F-C001-1115 | 3 | 1035 | 1115 | 293 | 68 | 64 | 29 |
3500@600 | CYQ35F-C001-1150 | 3 | 1035 | 1150 | 293 | 69.5 | 64 | 29 |
3500@600 | CYQ35F-C001-1200 | 3 | 1035 | 1200 | 293 | 71 | 64 | 29 |
3500@600 | CYQ35F-C001-1245 | 3 | 1035 | 1245 | 293 | 73 | 64 | 29 |
3500@600 | CYQ35F-C001-1300 | 3 | 1035 | 1300 | 293 | 74.5 | 64 | 29 |
3500@600 | 3 | 1035 | 1350 | 293 | 77 | 64 | 29 | |
3500@600 | CYQ35F-C002-1070 | 3 | 935 | 1070 | 293 | 69 | 64 | 29 |
3500@600 | CYQ35F-C002-1100 | 3 | 935 | 1100 | 293 | 70 | 64 | 29 |
3500@600 | CYQ35F-C002-1115 | 3 | 1035 | 1115 | 293 | 71 | 64 | 29 |
3500@600 | CYQ35F-C002-1150 | 3 | 1035 | 1150 | 293 | 72.5 | 64 | 29 |
3500@600 | CYQ35F-C002-1200 | 3 | 1035 | 1200 | 293 | 74 | 64 | 29 |
3500@600 | CYQ35F-C002-1245 | 3 | 1035 | 1245 | 293 | 76 | 64 | 29 |
3500@600 | CYQ35F-C002-1300 | 3 | 1035 | 1300 | 293 | 77.5 | 64 | 29 |
3500@600 | CYQ35F-C002-1350 | 3 | 1035 | 1350 | 293 | 80 | 64 | 29 |
Please Note that these units are designed to be used with fixed capacity.Please contact us for further advice if you propose to use in unusual environment.
