5 Tonnages Hyraulic Forklift Bale Clamp
1.Functions and Applications
Hydraulic forklift bale clamps accurately and effectively handle nearly any type of baled product including cotton,and synthetic textile bales,corrugated,newsprint,rag,hay,metal and other scrap bales without the need for pallets.
2. Features:
Proven,durable arm and aluminum frame construction ensuring long,useful lift of the clamp.
Superior arm-slide material and design for extended bearing life.
Low profile frame for visibility over the clamp.
Thin arm profiles for handling in between tightly spaced loads.
Regenerative hydraulic valving for optimal arm speed.
|
Capacity / Load Center |
Catalog Order No. |
Mounting Class |
Opening Range |
Arm Length |
Frame Width |
Arm Thickness |
Weight |
Effective Thickness |
Horizontal Center of Gravity |
| B | C | D | ET | HCG | |||||
| (kg@mm) | (mm) | (mm) | (mm) | (mm) | (kg) | (mm) | (mm) | ||
| 5000@800 | PBS-50D-005C | IV | 650-2370 | 1200 | 1475 | 106 | 1205 | 190 | 242 |
| 5000@800 | PBS-50D-006C | IV | 550-2270 | 1200 | 1575 | 106 | 1230 | 190 | 237 |
| 5000@800 | PBS-50D-007C | IV | 700-3100 | 1200 | 1980 | 106 | 1335 | 190 | 217 |
| 5000@800 | PBS-50D-008C | IV | 600-3000 | 1200 | 2080 | 106 | 1360 | 190 | 207 |
| 5000@800 | PBS-50D-009C | IV | 500-2900 | 1200 | 2180 | 106 | 1385 | 190 | 202 |
| 5000@800 | PBS-50D-010C | IV | 620-2340 | 1400 | 1475 | 110 | 1245 | 190 | 280 |
| 5000@800 | PBS-50D-011C | IV | 520-2240 | 1400 | 1575 | 110 | 1270 | 190 | 275 |
| 5000@800 | PBS-50D-012C | IV | 670-3070 | 1400 | 1980 | 110 | 1375 | 190 | 255 |
| 5000@800 | PBS-50D-013C | IV | 570-2970 | 1400 | 2080 | 110 | 1400 | 190 | 245 |
| 5000@800 | PBS-50D-014C | IV | 470-2870 | 1400 | 2180 | 110 | 1425 | 190 | 240 |
| 5000@800 | PBS-50D-015C | IV | 650-2370 | 1600 | 1475 | 115 | 1295 | 190 | 317 |
| 5000@800 | PBS-50D-016C | IV | 520-2240 | 1600 | 1575 | 115 | 1320 | 190 | 312 |
3.Options and Accessories:
Custom opening ranges.
Custom arm sizes.
Various mounting classes available.
Load backrests.
Bolt-on bale arm.
4.Packages
