Solar Cell 36 Poly or mono-crystalline 156×156mm |
Frame Anodized aluminium |
Weight 12kg |
Dimension 1483×665×35mm |
Module Type | RO 110-12 | RO 110-12 | RO 110-12 | RO 110-12 |
|
Nominal peak power(Wp) | 130W | 120W | 110W | 100W | |
Nominal voltage(Vmp) | 17.2V | 17.2V | 17.2V | 17.2V | |
Nominal current(Imp) | 7.56A | 6.98A | 6.40A | 5.81A | |
Open circuit voltage(Voc) | 21.60V | 21.60V | 21.60V | 21.60V | |
Short circuit current(Isc) | 8.02A | 7.50A | 6.98A | 6.61A | |
Module efficiency | 13.2% | 12.2% | 11.2% | 10.2% | |
Operating Temperature | -40oC to +85oC | -40oC to +85oC | -40 oCto +85oC | -40 oCto +85 | |
Maximum System Voltage | 1000V DC | 1000V DC | 1000V DC | 1 000V DC |
STC:1000W/m²,25
Product Features
1 Designed according to and complying with all requirements in IEC 61730 and IEC 61215 ed2(certified by TUV Rheninland);
2 White tempered glass,EVA ,weather proof substrate fim and anodized aluminium frame provide adequate protection against various environmental conditions
3 All backed by a 25 year limited power warranty(≥80%)and 2 year workmanship warranty
4 Customization on request
5 Cells are 100% visual inspected and sorted according to electric characters against mismatching
6 Visual inspection,performance measurement and dielectric strength tests on every product
7 The junction box and connectors with IP 65 protection degree provide convenient reliable electric connection;The incorporated schottky bypass diodes protect the module from hot spot damages
Welcome to contact us if U have any questions~
