Temperature Coefficients
NOCT 45+/-2 oC |
Voltage temperature coefficient(Voc) -0.36%/ oC |
Current temperature coefficient(Isc) +0.033%/ oC |
Power temperature coefficient(Pmpp) -0.44%/ oC |
Minimum power tolerance +/-10%oC |
NOCT: Nominal Operating Cell Temperature
Mechanical Data
Solar Cell |
Mono-crystalline 156×156mm |
Frame |
Anodized aluminium |
Weight |
4kg |
Dimension |
634×534×35mm |
Warranty and certifications
Warranty 3 years workmanship,10 years90%,25 years 80% power warranty |
Certifications TUV , CE |
Electrical Data
Module Type |
RO 043-12 |
RO 040-12 |
RO 038-12 |
Nominal peak power(Wp) |
43W |
40W |
38W |
Nominal voltage(Vmp) |
17.2V |
17.2V |
17.2V |
Nominal current(Imp) |
2.50A |
2.33A |
2.20A |
Open circuit voltage(Voc) |
21.6V |
21.6V |
21.6V |
Short circuit current(Isc) |
2.84A |
2.65A |
2.51A |
Module efficiency |
12.7% |
11.9% |
11.3% |
Operating Temperature |
-40 to +85oC |
-40 to +85oC |
-40 to +85 oC |
Maximum System Voltage |
1000V DC |
1000V DC |
1000V DC |
STC:1000W/m²,25
Product Features:
1 Designed according to and complying with all requirements in IEC 61730 and IEC 61215 ed2(certified by TUV Rheninland);
2 White tempered glass,EVA ,weather proof substrate fim and anodized aluminium frame provide adequate protection against various environmental conditions
3 All backed by a 25 year limited power warranty(more than 80%)and 2 year workmanship warranty
4 Customization on request
5 Cells are 100% visual inspected and sorted according to electric characters against mismatching
6 Visual inspection,performance measurement and dielectric strength tests on every product
7 The junction box and connectors with IP 65 protection degree provide convenient reliable electric connection;The incorporated schottky bypass diodes protect the module from hot spot damages
