KB-125C Jiangsu manufacturer Concrete roof tile making machine
(tiles making machine, roof tile machine/ concrete roof tile making machine)
-- cement + sand
-- 3000 pcs per shift, (300-400m2 per shift)
-- full automatic
-- mixer, elevator, feeder, moulding machine and pallets
-- iron moulds, metal pallets
Charactor for KB-125C Jiangsu manufacturer Concrete roof tile making machine
1.The machine adopts PLC programmable controller featuring fast molding speed,large output,automatic control, man-machine interface, reliable performance and convenient operation. It has 7-8 pcs/min, whole hydrao-pneumatic production speed, high rate of finished producs and high cost performance.
2.As a competitive concrete products making equipment, its products adopts mortar oncrete filter pressing molding and features perferct structure. Various style, high density, high intersity and accurate size, which can meet the needs of different constructions.
3.It is multifunctional machine,it can be used to produce various styles of main tiles, ridge tiles. Edge tiles and ditch tiles after changing the molds as well as different styles of high grade concrete ground tiles,such as terrazzo tiles, stripe tiles, wall tiles and so on.
4.Its remote diagnosis system,which can be used to control and diagnosis the equipment remotely through the phone line,greatly reduces the requirement for customers and makes the machine more humanization.
5. KB-125C Concrete roof tile making machine has a high quality but low price, occupies the market share by its perfect products.
6.Stuffer pot adopts unique feeding head design, which ensures the complete matching of large quantity of filler incorporation and uniformity of threading, with high production of the complete machine.
specification for KB-125C Jiangsu manufacturer Concrete roof tile making machine
| KB-125C Concrete roof tile making machine | |
| moulding presure | 120T |
| moulding speed | 7-8pcs/min,more than 3000pcs/shift |
| main frame power | 5.5 KW |
| main frame weight | about 5 tons |
| external dimension | 2700*1600*2480mm |
Motor power parameter for KB-125C Jiangsu manufacturer Concrete roof tile making machine
| motor power of tile moulding machine | 5.5 KW |
| motor power of elevator | 3.0 KW |
| motor power of mixer | 7.5 KW |
| motor power of feeder | 3.0 KW |
| motor power of the air compressing machine | 7.5 KW |
Optional accessory
| 1 | strainer |
| 2 | filter cloth |
| 3 | mould oil |
| 4 | air compressor |
| 5 | tile paint |
| 6 | paint gun |
| 7 | drying tile rack |
| 8 | plate |
| 9 | ridge tile vibration table |
| 10. | three-way and four-way manual mould |
Working machine for KB-125C Concrete roof tile making machine:
Raw material of our roof tiles, cement 425# and river sand normally, ratio as below:
Raw materials |
Specification |
Ratio(kg) |
Notes |
Cement |
P.O or P.S 32.5# |
50 |
|
Sandr |
Medium sand |
80~100 |
|
water |
0.5~1.0 |
optional |
Notes:
1.cement:sand = 1:1.5~2.0 (weight)
2.water : cement = 1:0.25~0.35. The water should not be too much, otherwise tile will stick to mould.
3. can be added suitable little chemical material
Manufacturing process for KB-125C Concrete roof tile making machine
Cement + sand -- Elevating - Mixing - Fixed-quantity filling -Pressure forming- Mould unloading - Forming tiles - Maintenance - Finished products
1. At frist,the raw materials are put into the bucket elevator, then deliver to the rolling mixer,at this time,you must add some water into it.
2. After mixing, the mixture come into the dosing feeder,then,measurable mixture that one tile need will put down on the mould below through a small hole.
3. Then,a tile can be formed by high pressure,the pressure is about 125 tons. So the produced tile is very stable and dense.I think the constructor can boldly walk on the paved roof.
4. By the way,the tile need to dry out for about 3-7 days.Then you can paint.
During this process, many customers are confused how to put colors outside roof tiles. In fact there are two ways :
way 1: put colorful pigment inside mixer, together pressured by our machine.
way 2: after pressued by our machine, paint different color outside roof tiles.
Finished roof tiles of KB-125C Concrete roof tile making machine showing with different colors and shapes:
Usage of finished products
equipment composed parts for KB-125C Concrete roof tile making machine
| # | Product Name | |
| 1 | one bucket elevator | |
| 2 | one vertical mixer | |
| 3 | one quantitative feeding mixer | |
| 4 | one moulding machine | |
| 5 | one hydraulic forklift | |
| 6 | one manual ridge/edge tile making machine | |
| 7 | 2000 pieces of steel tile moulds | |
| 8 | 5 pieces of plastic ridge tile moulds and 5 pieces of plastic edge tile moulds | |
details picture of each parts for KB-125C Concrete roof tile making machine,
elevator has a bucket to hold mixer cement and sand
wheel mixer after elevator of material
constant feeder after mixer and before moulding
Functional products -- floor tiles and stripe tiles
delievery packaging & shipping for KB-125C Concrete roof tile making machine
Our Service:
Before-sale services:
(1) Tell customer how to build a brick plant, the complete plant including three parts, brick shaping machinery, drying and firing.(Confirm clay,power electricity,water,land area, fund)
(2) Guide customers to choose the best and economic plant, recover the investment within short time.
(3) site inspection
(4) We are responsible for the offer, flow chart, and detail specification of each machinery.
In-Sale services:
(1)Quality control must be inspected strictly
(2)In accordance with the agreements stipulated in the contract
After-sale services:
(1) We will send the technicians to guide with device installation, debugging and training operators until customers are fully satisfied.
(2) Guarantee for machinery, materials and equipment supplied under this quotation are valid for a period of 12 months after commissioning or 16 months after delivery whichever is earlier. Warranty shall cover manufacturing defect in material and workmanship but exclude:
a. Daily wear and tear 2.mishandling or improper operation3. Incoming power supply fluctuation
b. Consumable and spare parts.
(3) Regular visit customer, consult with the customer feedback, come true with the customer's two-way communication.
Our company YANCHENG KEBO HYDRAULIC TILE MACHINE MANUFACTURER
Guarantee and service after-sale
. one year guarantee for whole machine except consumption
. 24 hours technical support by email
. calling or door to door service
. ues-friendly english software, user manual, and details video
for details information pls feel free to contact following information with me, if you have time, welcome you to visit our factory for KB-125C Concrete roof tile making machine
