KB-125C hdyraulic press concrete roof tile machine
(roof tile machine, concrete roof tile machine)
-- material: cement + sand + water
-- capacity: more than 3000pcs per shift
-- hydraulic pressure 120 tons
-- also can make other tiles ( stripe tiles, wall tiles, floor tiles ) by changing mold
roof tiles for KB-125C concrete roof tile machine
Raw material and working process for concrete roof tile machine
Raw materials |
Specification |
Ratio(kg) |
Notes |
Cement |
P.O or P.S 32.5# |
50 |
|
Sand |
Medium sand |
80~100 |
≤dia5mm |
water |
Water-reducing agent |
0.5~1.0 |
optional |
1. At first, the raw materials are put into the bucket elevator, then deliver to the rolling mixer,at this time,you must add some water into it.
2. After mixing, the mixture come into the dosing feeder,then,measurable mixture that one tile need will put down on the mould below through a small hole.
3. Then, a tile can be formed by high pressure, the pressure is about 120 tons. So the produced tile is very stable and dense. I think the constructor can boldly walk on the paved roof.
4. By the way, the tile need to dry out for about 3-7 days.Then you can paint.
specification for KB-125C concrete roof tile machine
| KB-125C concrete roof tile machine | |
| moulding presure | 120T |
| moulding speed | 7-8pcs/min,more than 3000pcs/shift |
| main frame power | 5.5 KW |
| main frame weight | about 5 tons |
| external dimension | 2700*1600*2480mm |
Composed parts for KB-125C concrete roof tile machine
| moulding machine | 1 set |
| mixer | 1 set |
| elevator | 1 set |
| feeder | 1 set |
| tile mould | 1 set |
Motor power parameter for KB-125C concrete roof tile machine
| motor power of tile moulding machine | 5.5 KW |
| motor power of elevator | 3.0 KW |
| motor power of mixer | 7.5 KW |
| motor power of feeder | 3.0 KW |
| motor power of the air compressing machine | 7.5 KW |
Optional accessory
| 1 | strainer |
| 2 | filter cloth |
| 3 | mould oil |
| 4 | air compressor |
| 5 | tile paint |
| 6 | paint gun |
| 7 | drying tile rack |
| 8 | plate |
| 9 | ridge tile vibration table |
| 10. | three-way and four-way manual mould |
Detail parts showing for KB-2400B concrete roof tile machine
Features for KB-125C concrete roof tile machine
1.Unique Water-proof Structure
Only the moulding tile have the valley bottom structure,which is very useful for the discharge of the rain, and can be effectively to avoided the reflux of the rain.What's more, the higher part of the tile's head can never make the reflux of the rain, even on the horizontal roofing.
2.Superhigh Strength
The tile produced by moulding machine has superhigh strength, about 1250 KN, and the overall dimension is very accurate(425mm×337mm,about 9 pcs/m²).The density is very homogeneous, the rupture strength is more than 200 KG, which can bear the constructor's weight easily.
3. The roof tile machine has excellent design, hydraulic pressure,button operating.
4. It adopts the original mixing together with PC, mechanical, electrical, hydraulic and gas technique. Full automatic control,the overall system is more reliable and stable.
5. The concrete roof tile machine has high technology, high capacity, less investment and more harvest.
The characters for roof tiles
1. The tiles which are formed by the machine can make the rain discharged more smoothly and faster, even if it is used in a horizontal roof, there will be no rain counterflow case.
2. The tiles produced by the machine has high strength, the pressure is about 1.25 million Newton, and the overall dimension is very accurate(425*337mm). 9pcs are used per square meter.The rupture strength is more than 200 kilogram,so the constructor can boldly walk on the paved roof.
3. Whether vertical paved or horizontal paved,construction is always convenient. It doesn’t need to hang battens if on the common slope roof.The tiles can be cut conveniently by cutting machine at any angle.
4. The heat insulation and frost resistance of tiles are better than other tiles.
5. Because the tile is produced by high pressure,it’s penetration resistance is very well.It is usually used in long-term rain and snow area.
Different customer tiles showing as below for KB-125C concrete roof tile machine
functional tiles for KB-125C concrete roof tile machine by changing mold
packaging & shipping for KB-125C concrete roof tile machine
one 40ft can hold whole line equipments. we put bubble bag outside machine preventing wet surrounding. Container will come to our workshop , we put inside equipment.
our services
we send engineer going to customer's side for installatio and training customers
our guarantee time is one year. even exceed one year, we also help you to solve versions
company information
we locate in Jiangsu province, about 15000m2 workshop, three workshops, welcome your visit our factory to give us better suggestion and idea
FAQ:
1. How about the Delivery time?
Lead time since receipt of 30% T/T deposit payment: 30 days. Samples will be prepared within 5 Days.
2. What kind of payments does jenor support?
T/T, L/C, Western Union, PayPal & Cash are accepted.
3. Can you produce according to customers' design?
Sauce, we are professional manufacturer; OEM and ODM are both welcome.
4. How many days of your production?
Usually we need 30 days to prepare equipments after receipt deposit or L/C.
5. Do you have guarantee?
yes, we have. Our guarantee time is one year. even exceed one year, any problem you can asked us to help you.
if you like more details information, please feel free to contact with me of following information. If you have time, welcome you to visit our factory:
