Sludge Thickening Dehydrator

Belt type sludge dewatering machine

 Working principle:

The whole working principle of belt type filter press is divided into three stages: sludge flocculation, filter press gravity dewatering and pressing dewatering.

Sludge belt filter is pressing in original belt type filter based on increased concentration, sludge inspissation machines including condensed section, dehydration section, sludge mixed reaction system, which can be directly can put the second pond sludge (99.2-99.6%) moisture content of concentrated dehydration, eliminating the traditional enrichment pool, saving a lot of investment.

Belt filter is a process of concentrated (moisture content 95-98%) material further into the effective filter cake dehydration with continuous automatic production equipment, production cost is low, equipment installation, and can change the characteristics of different mesh filters, continuous stepless speed regulation, to adapt to different kinds of material solid-liquid separation. Whole structure is reasonable, prevent water splashed outside, high accuracy, roll system installation fewer adjust deviation, extended the filters, bearings, and pneumatic components life, main transmission adopts motor stepless speed regulation, increases the speed range, smooth operation, rinse water front increased cleaning brush, improved filters rinse rinse water, reduce the effect of sludge dewatering rate, increase.

Properties and USES
YIMEI belt type filter press is a new high-efficiency sludge treatment equipment developed by our company based on the digestion and absorption advanced foreign technology , it has high efficiency, low energy consumption, dehydration, simple structure, easy maintenance, low noise, smooth operation, safe and reliable, continuous automatic production, etc. now widely used in petroleum, chemical, coal, metallurgy, building materials, textile, food and water environmental protection engineering solid-liquid separation etc.

Sludge belt filter press increased concentration based on original belt filter press , sludge inspissation machines including condensed section, dehydration section, sludge mixed reaction system, which can put the second pond sludge (water ratio 99.2-99.6%) concentrated dehydration directly, thus eliminating the traditional enrichment pool, saving a lot of investment.

Belt filter is an efficiency equipment by dehydrating process of concentrated (water ratio 95-98%) material into filter cake dehydration ,with the feature of continuous automatic production equipment,  low production cost and installation, can change different mesh filters, continuous stepless speed regulation, adapting to different kinds of material solid-liquid separation. Whole  structure is reasonable, prevent water splashed outside, roller inatalltion  high accuracy, fewer adjust deviation, extended the filters, bearings, and pneumatic component’s life, main transmission adopts motor stepless speed regulation, increases the speed range, operation stable, rinse water front increased cleaning brush, improved filters washing effect, reduce wash water consumption ,increase the rate of sludge dewatering.

Main technology parameter:

2.1 Belt type filter press

2.1.1 filter press reducer model number: SA70 DT90S NA15  B51 d60(frequency control of motor speed)

2.1.2 reducer`s power: 1.5KW

Properties and USES
YIMEI belt type filter press is my company in the digestion and absorption of advanced foreign technology developed by the basis of new high-efficiency sludge treatment equipment, it has high efficiency, low energy consumption, dehydration, simple structure, easy maintenance, low noise, smooth operation, safe and reliable, continuous automatic production, etc. Is now widely used in petroleum, chemical, coal, metallurgy, building materials, textile, food and water environmental protection engineering solid-liquid separation.

Sludge belt filter is pressing in original belt type filter based on increased concentration, sludge inspissation machines including condensed section, dehydration section, sludge mixed reaction system, which can be directly can put the second pond sludge (99.2-99.6%) moisture content of concentrated dehydration, eliminating the traditional enrichment pool, saving a lot of investment.

Belt filter is a process of concentrated (moisture content 95-98%) material further into the effective filter cake dehydration with continuous automatic production equipment, production cost is low, equipment installation, and can change the characteristics of different mesh filters, continuous stepless speed regulation, to adapt to different kinds of material solid-liquid separation. Whole structure is reasonable, prevent water splashed outside, high accuracy, roll system installation fewer adjust deviation, extended the filters, bearings, and pneumatic components life, main transmission adopts motor stepless speed regulation, increases the speed range, smooth operation, rinse water front increased cleaning brush, improved filters rinse rinse water, reduce the effect of sludge dewatering rate, increase.

Main technology parameter:

2.1 Belt type filter press

2.1.1 filter press reducer model number: SA70 DT90S NA15  B51 d60(frequency control of motor speed)

2.1.2 reducer`s power: 1.5KW

2.1.3 treatment capacity: 3-10m3/h

2.1.4 belt speed of Presses filter machine: 5-12m/min

2.1.5 effective width of  filter belt: 1000mm

2.1.6 speed regulating style: stepless speed regulating

2.2 Belt type filter press

2.2.1 effective width of belt: 1000mm

2.2.2 filter line`s range of speed: 1.5-6.0m/min

2.2.3 speed regulation style: stepless speed regulating

2.2.4 Main transmission motor power:  1.5KW

2.2.5 treatment capacity:  10-13m3/h

2.2.6 filter cake moisture content: ≤75%
