Help CenterElctrical Plating Line
Related Products
-
Electrolytic Plating MachineNegotiableMOQ: 1 Set -
Electrolytic Single Wire Plating Machine (Ni/Sn)NegotiableMOQ: 1 Set
-
Electrolytic Wire Plating Machine Wire and Cable MachineNegotiableMOQ: 1 Set
-
Electrolytic Single Wire Plating MachineNegotiableMOQ: 1 Set
-
Electrolytic Single Wire Plating MachineNegotiableMOQ: 1 Set
TECHNICAL DATA:
Type of line : HT- 3000 Ag -10 m/s
Length : approx. 19,000 mm (incl. stairs and accessories)
Width : approx. 6,800 mm
Height (cover copened) : approx. 2,500 mm
Weight without bath liquids : approx. 10,000 kg
Weight with bath liquids : approx. 18,000 kg
Number of wires : one
Wire speed : max. 10 m/s
Wire material : Cu, hard and soft
Wire diameter range : 0.9- 2.6 mm
Condition of wire : low grease and free from oxides
Coating material : Ag
Coating thickness : 1 to 20 µm
Coating quality : as per DIN, ASTM
Total installed load : approx.140 kW
Mains voltage : 3 x 380 / 50 Hz
Control voltage : 24 V DC, 220 V AC
Electric equipment : acc. to VDE and VBG 4
Max. ambient temperature : 45°C (hall temperature)
Noise level : max. 85 dB (A) average sound level,
acc. to DIN 45635
Plating current : 3000 A, 8 V
Degreasing current : 500 A, 8 V
Immersion length, plating : 3 x 160 m = 480 m
Immersion length, degreasing : 67 m
Immersion length, silver-strike :18 m
Dia. of current roller, plating :400 mm, 27 turns
Dia. of current roller, degreasing : 400 mm, 23 turns
Dia. of current roller silver-strike : 400 mm, 8 turns
Send Inquiry to This Supplier
