Electrolytic Single Wire Plating Machine (Ni/Sn)

Electrolytic Single Wire Plating Machine (Ni/Sn) thumbnail-1
Electrolytic Single Wire Plating Machine (Ni/Sn) thumbnail-2
Electrolytic Single Wire Plating Machine (Ni/Sn) thumbnail-3
Electrolytic Single Wire Plating Machine (Ni/Sn) thumbnail-4
Electrolytic Single Wire Plating Machine (Ni/Sn) thumbnail-5
Electrolytic Single Wire Plating Machine (Ni/Sn) thumbnail-6
Electrolytic Single Wire Plating Machine (Ni/Sn) photo-1
Electrolytic Single Wire Plating Machine (Ni/Sn) photo-2
Electrolytic Single Wire Plating Machine (Ni/Sn) photo-3
Electrolytic Single Wire Plating Machine (Ni/Sn) photo-4
Electrolytic Single Wire Plating Machine (Ni/Sn) photo-5
Electrolytic Single Wire Plating Machine (Ni/Sn) photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT- 5400 Ni-15 m/s
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT- 5400 Ni-15 m/s
Usage Coating

Specifications

Electrolytic tin plating machine:
Wire speed : max. 15 m/s
Wire material: Cu, hard and soft
Wire dia.: 0.5-1.2mm

 Technical Data of HT- 5400 Ni-15 m/s Electrolytic Single Wire Plating Line (Ni):



 Type of line: HT- 5400 Ni-15 m/s

 Length: approx. 19,000 mm (incl. stairs and accessories)

 Width: approx. 6,800 mm

 Height (cover copened) : approx. 2,500 mm

 Weight without bath liquids: approx. 10,000 kg

 Weight with bath liquids: approx. 18,000 kg

 Number of wires: one

 Wire speed: max. 15 m/s

 Wire material: Cu, hard and soft

 Wire diameter range: 0.5 -1.2 mm

 Condition of wire: low grease and free from oxides

 Coating material: Ni

 Coating thickness: 1 to 65 µm

 Coating quality: as per DIN, ASTM

 Total installed load:  approx.160 kW

 Mains voltage: 3 x 380 / 50 Hz

 Control voltage: 24 V DC, 220 V AC

 Electric equipment: acc. to VDE and VBG 4

 Max. ambient temperature: 45°C (hall temperature)

 Noise level: max. 85 dB (A) average sound level ,

                        acc. to DIN 45635

 Plating current: 5400 A,  12 V

 Degreasing current: 300 A,    8 V

 Immersion length, plating: 3 x 160 m = 480 m

 Immersion length, degreasing:  67 m

 Immersion length, pickling:  18 m

 Dia. of current roller, plating:  400 mm,  27 turns
 Dia. of current roller, degreasing:  400 mm, 23 turns
 Dia. of capstan, pickling:  400 mm, 8 turns
