12v 24v 48v Led Driver CE ROHS
- Shenzhen
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SANPU | |
| Model Number | L200-H1V | Output Power | 101 - 200W | |
| Output Type | Single | Input Voltage | 220V | |
| Output Voltage | 5V 12V 15V 24V 27V 48V | Output Frequency | 47~63Hz | |
| Output Current | 0~40A |
Product Description
Specifications
1. 12v 24v 48v led driver CE ROHS2. 100% full load burn-in test
3. Small- volume high-efficiency
4. Two years warranty
Features
1.12v 24v 48v led driver CE ROHS
2.Protections: short circuit/ over load/ over voltage/ over temp
3. Conform to EN60950 GB4943 UL60950 Safety standards
4. Conform to CB9254 EN55022 EMC Standards
5. High quality with competitive price
6. Suitable for any where in the world
7. Built-in EMI filter with tiny ripple
8. Two years warranty
9. Life span: 50,000H
AC input voltage range | 85~132VAC 170~264VAC 47~63Hz | ||||
Input current | 4A/115V 2A/230V | ||||
AC inrush current | Cold-start current 25A/115V 50A/230V | ||||
Leakage current | <3.5mA/240VAC | ||||
DC adjustable range | ±10% rated output voltage | ||||
Over load protection | 105~135% hiccup mode, auto-recovery | ||||
Over-voltage protection | 115~135% Cut offthe output, auto-recovery | ||||
Over-temp protection | Rectifier≥105 °C cut off the output, auto-recovery | ||||
Setup, rise, hold up time | 200ms, 100ms, 20ms | ||||
Withstand voltage | I/P- O/P: 1.5KVAC 1 minute I/P- FG: 1.5KVAC 1 minute O/P- FG: 0.5KVAC 1minute | ||||
Working temperature | -20 °C ~+60°C, 20%~90%RH | ||||
Weight/ packing/ size | 0.66Kg, 40pcs/26.5Kg, 223*71*39(mm) | ||||
Model | Output | Error | Range | Efficiency | |
L 200- W1V5 | 5V | 0~40A | ± 2% | 120mv | 81% |
L 200- W1V12 | 12V | 0~16.5A | ± 1% | 150mv | 84% |
L 200- W1V15 | 15V | 0~13A | ± 1% | 150mv | 84% |
L 200-W1V24 | 24V | 0~8.3A | ± 1% | 150mv | 85% |
L 200-W1V27 | 27V | 0~7.4A | ± 1% | 150mv | 85% |
L 200-W1V48 | 48V | 0~4.2A | ± 1% | 200mv | 86% |
