Help CenterASTP-Y Adjustable Digital Auto Electronic Multi Range Time Delay Relay With CE
Related Products
-
AH2-N Surface Mounted Type Electric Adjustable Sequencer Time Relay With CEUS$ 4.5 - 6.5MOQ: 10 Pieces -
AH2-Y Flush Type Mounting Electric Adjustable Sequencer Time Delay Relay With CEUS$ 5.5 - 7.5MOQ: 10 Pieces
-
AH2-N/Y Flush Type Mounting Electric Adjustable Sequencer Timer Delay Realy With CEUS$ 5.5 - 7.5MOQ: 10 Pieces
-
ATDV-N Flush Mounted Type Manufacturer Twin Double Timer Relay With CEUS$ 5.5 - 8.5MOQ: 10 Pieces
-
ATDV-Y Flush Mounted Type Electronic Manufacturer Twin Time Relay With CEUS$ 5.5 - 9.5MOQ: 10 Pieces
Operation precision: AC:36V 110V 127V 220V 380V DC: 24V
Delaying specification: 1s 3s 5s 10s 30s 60s 120s 180s 6m 30m 60m
Delaying precision: <5%
Contact capacity: AC250V 5A
Contact electric life: 105
Ambient temperature: -5°c~+40°c
Mounting mode: Front-panel type
Type |
ASTP-N |
ASTP-Y |
|||
Dimensions |
61HX49WX70D |
88HX58WX68D |
|||
Mounting |
Surface (-N) |
PF083A(E) PS-08 |
|
||
Socket |
Flush(-Y) |
|
US-08 P3G-08 |
||
Full timing range |
SEC:1,3,6,10,12,30,60 MIN:3,6,12,30,60 HR:3,6,12,24 |
||||
Rated voltage |
DC(V):12,24 AC(V):12,24,110,220,240,50/60Hz |
||||
Indicator operation |
Time operationt |
||||
|
O/P Contact |
Model |
STP-N1/ STP-Y1 |
STP-N2/ STP-Y2 |
STP-N/ STP-Y |
|
Time limit 1c |
5A |
5A |
5A |
||
Time limit 2c |
|
|
|
||
Instantaneous 1c |
|
|
5A |
||
Service life |
Mechanical |
5000000 times |
|||
Electrical |
100000 times |
||||
Accuracy |
Repeat error |
±1% max |
|||
Setting error |
±10% max |
||||
Voltage error |
±1% max |
||||
Temperature error |
±2% max |
||||
Reset time |
0.1 sec max |
||||
Consumed power |
2VA |
||||
Ambient temperature |
-10~+55 |
||||
Ambient humidity |
48-85% RH |
||||
Weight |
220g |
||||
What is the packing for our product?
What is the delivery way?
(1)If ship by sea and Air,you can get Bill of Loading,CO,Commerical invoice,Packing list from us after ship.
(2)If ship by express company,you will get a Tracking No. from us after ship.
What the Certifications do we have obtained?
What is the payment?
What's the Refund & Replacement?
1. 90-day-warranty.
If there is any quality problem (defective / don't work) of the goods, it could be returned within the warranty days. (Please notify us as soon as possible)
2. Any items must be returned in their original condition to qualify for a refund or replacement. (Any used items cannot be refunded or replaced).
Company view
Our team
What is the MOQ of our Time Relays?
MOQ: We support sample order.(1~5PCS)
More than 500PCS,can pring Logo on the products.
How to Visit and contact us?
Firstly, you are highly welcomed to visit our factory, we can provide you an invitation letter from Chinese Embassy for you if needed.
Besides, we are more pleased to help you to book a flight or hotel to save your time.
