AH2-N/Y Flush type Mounting Electric Adjustable Sequencer Timer Delay Realy with CE
- 10000 Piece / Pieces per Month
- Ningbo/Shanghai
- T/T Credit Card PayPal
- SR489-P5-HI-A20-E Protective relay Has a variety of input and output modes
- PPD113-B03-23-111615 Inverter processor The reliability of the system is improved
- PPD113B03-26-100110 Input module Powerful processing power
- 5SHY3545L0009 Power semiconductor device System reliability
- IS215UCVGM06A IS215UCVGH1A Single-socket CPU module Multiple extension or remote substrates
- PFTL201C 10KN 3BSE007913R0010 Tension sensor Able to capture more comprehensively
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Winston | Model Number: | AH2-N/Y |
Theory: | Time Relay | Usage: | Auto | Size: | Miniature |
Protect Feature: | Sealed | Contact Load: | Low Power |
Product Description
AH2-N/Y Flush type Mounting Electric Adjustable Sequencer Timer Delay Realy
Features
Voltage:AC 12V-AC 380V DC 24V-DC 12V
F:50/60Hz
Comtact:Time 1 SPDT lnst.1SPDT
Operation:On-delay with ntact
Timing Range:1S.2S.3S.6S.10S.12S
30S.60S.2M.3M.5M.6M
10M.30M.12M.60M.3H
6H.12H.24H
Technique parameter
Type | AH2-N/Y | |
Dimensions | 61HX49WX70D 88HX58WX68D | |
Mounting | Surface (-N) | PF083A(E) PS-08 |
Socket | Flush(-Y) | US-08 P3G-08 |
Full timing range | A:1S,10S,1M,10M B:3S,30S,3M,30M C:6S,60S,6M,60M D:1M,10M,1H,10H E:3M,30M,3H,30H | |
Rated voltage | DC(V):12,24 AC(V):12,24,110, 220,240,50/60Hz | |
Indicator operation |
| |
O/P Contact | Model | AH2-N/Y |
Time limit 1c | 5A | |
Time limit 2c | 5A | |
Instantaneous 1c | 5A | |
Service life | Mechanical | 5000000 times |
Electrical | 100000 times | |
Accuracy | Repeat error | ±1% max |
Setting error | ±10% max | |
Voltage error | ±1% max | |
Temperature error | ±2% max | |
Reset time | 0.1 sec max | |
Consumed power | 3VA | |
Ambient temperature | -10~+55 | |
Ambient humidity | 48-85% RH | |
Weight | 220g |
Dimension
Packaging & Shipping
Certifications
FAQ
Q: How to order our product ?
A:1). Please tell us the model and quantity and other request you need.
2). We make the PI for you.
3). After you confirm the PI, we arrange the order for you after receiving your payment.
4). After the goods finished, we send the goods out to you and tell you the tracking number.
5). We will track your goods until you receive the goods.
Q: What's your warranty ?
A: Two years
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by Maoyt or send us by email, we will reply within 24hrs.
