Specifications
1. German FESTO cylinder.2. Japanese SMC solenoid valve.
3. Precise printing, steady and durable.
4. CE approved.
Flat Screen Printing Machine JN-400P
A universal model which is very popular in southeast Asia market.
This kind of machine is suitable for printing on various materials such as wood, plastic, metal, glass, leather, cosmetics, gifts, or ceramic etc.
Be widely used in electronic industry, advertising, packing & printing, sports equipment, toy, stationery, gifts, industrial arts fields etc.
Printing objects such as decal, cards, transfer paper, pester, sticker, PVC/PET/PC films, metal nameplate etc which are made of non-deforming materials
Feature:
1. Advanced computerized system control.
2. Built-in LED digital counter.
3. Light-weight, strong aluminum cast machine frame.
4. Pneumatically driven adopt from FESTO, can adjust the movement speed of each part.
5. Can be operated in manual and semi-auto mode to suit different worker's skill level.
6. Horizontal movement of screen frame can be adjusted to fit your various printing needs.
7. Squeegee/flood bar depth, pressure, speed, leveling, and stroke etc., are all adjustable to fit your various printing needs.
8. Adopt German FESTO components.
9. Machine running fast and stable, low nosie.
Specifications:
1. Thickness of printing matter: 0~60mm
2. Size of printing table: 300× 500mm
3. Max Printing area: 250× 350mm
4. Max Stroke of up-and-down frame: 160mm
5. Max. Printing speed: 1500Pcs/Hr
6. Air pressure: 6 Bar
7. Power voltage: AC 110V/220V 60Hz/50Hz
8. Power consumption: 35 W
9. Machine dimension: 950 * 970 * 1550 mm
10. Machine weight: 182 Kg.
