Specifications
1. German FESTO cylinder.2. Japanese SMC solenoid valve.
3. Precise printing, steady and durable.
4. CE approved.
High Precision Flat Screen Printing Machine JN-6090P
This machine design for large planar screen printing, such as: Paper, glass, PVC, and so on. Printing objects such as decal, cards, transfer paper, pester, sticker, PVC/PET/PC films, metal nameplate etc which are made of non-deforming materials.
With the off-grid unit, it can depart the screen frame and printing object smoothly, ensure the good quality of printing design, it is easy to clean the screen frame by the auto rising printing head.
Advantage:
Microprocessor control, moter driving for left & right printing movement through linear guide rail, moter driving for up & down movement through linear guide rail, PLC control with touch screen panel is optional.
Easy operation, accurate movement, precision printing.
Features:
1. Microprocessor control, (PLC control with touch screen panel is optional).
2. Built-in LED digital counter.
3. Light-weight, strong cast aluminum machine frame.
4. Pneumatically driven adopt from FESTO, can adjust the movement speed of each part.
5. Can be operated in manual and semi-auto mode to suit different worker's skill level.
6. Horizontal movement of screen frame can be adjusted to fit your various printing needs.
7. With the snap-off unit, it can depart the screen frame and printing object smoothly, ensure good printing quality.
8. Squeegee / flood bar depth, pressure, speed, leveling, and stroke etc., are all adjustable to fit your various printing needs.
9. Linear guide rail and the slider left and right, to ensure the printing precision.
10. Imported converter, the required printing speed key adjust printing.
11. With a jog/step/round robin/automatic function to switch easily.
12. Table with foot switch/emergency stop button, ensure the needs of the printing process and operating personnel.
13. Machine running fast and stable, low nosie.
Specifications:
1. Thickness of printing matter: 0~50mm
2. Size of printing table: 700× 1000mm
3. Max Printing area: 600× 900mm
4. Max Stroke of up-and-down frame: 280mm
5. Max. Printing speed: 600 Pcs/hour
6. Air pressure: 6 Bar
7. Power voltage: AC 110V / 220V
8. Power consumption: 200 W
9. Machine dimension: 1560× 1280× 1800mm
10. Machine weigh: 300Kg
